Digital Ultrasonic Wall Thickness Gauge SA40 4 Digits LCD With Backlight

Digital Ultrasonic Wall Thickness Gauge SA40 4 Digits LCD With Backlight thumbnail-1
Digital Ultrasonic Wall Thickness Gauge SA40 4 Digits LCD With Backlight photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
SADT
Place of Origin:
China
Model Number:
SA40
Contact Supplier Request Quote Chat Now
Sino Age Development Technology, Ltd,
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name SADT
Place of Origin China
Model Number SA40
Delivery Time:Within 3 days after receiving payment
Certification:ＣＥ　ＩＳＯ９００１

Digital Ultrasonic Wall Thickness Gauge SA40 4 Digits LCD With Backlight

SA40 is the miniaturized ultrasonic thickness gauge that can measure wall thickness and velocity. Our intelligent gauge is designed to measure the thickness of metallic and non-metallic materials such as steel, aluminum, brass, silver, oil, acrylic resin, glycerin, water glass and etc. It is quite versatile model which can be easily equipped with the low & high frequency probes as well as a high temperature probe.

Details:


Specifications:


Technique: pulse echo with dual probe
Display: 4 digits LCD with backlight
Measuring range: 0.8 to 225.0mm
Resolution : 0.01mm@0.8-99.99mm, 0.1mm@100.0-225.0mm
Velocity range: 500-9999m/sec.
Display circle: 1 sec.
Coupling indication
Memory: 40 data can be stored and re-readable
Units: mm or inch
Low battery indicator on LCD
Auto shut-off: after 5 min. of non-use
Power: 2 ea. 1.5V AA alkaline cells
Operating temperature: 0-40°C
Operating humidity: 20-90%RH
Weight: 240g

PT-5        5MHZ         Dia.Φ10mm       For standard applications
XT-5        5MHZ         Dia.Φ7mm        For tubes with small diameter
GT-5        5MHZ         Dia.Φ12mm       For high temperature up to 400℃
