PE / PC / PP Pipe Plastic Extrusion Mould , Pipe Diameter 16mm-800mm
Quick Detail:
1)Pipe diameter:16mm-800mm
2)Type:pipe mould
3)Certificate:CE, ISO
4)Single outlet
PE pipe mould , PE-RT pipe mould , PP-R pipe mould
Description:
This type of die head system adopts the optimized design to ensure superfine and steady quality of products under low melting temperature.
1)With high output and low consumption of energy, it realizes two color extruded by one system.
2)It is applicable to all TEO materials.
3)It also has a big scope of product dimensions fromΦ16mm to Φ800mm.
4)Not being affected by the changing of material viscidity, this mould is applicable
to produce pipe products of HDPE/MDPE, LDPE, PP/PPR, PB/ABS and DMWPE
with steady processing performance.
5)Due to low pressure in the die head system, it maintains low melting temperature even in high quantity of extrusion.
6)It‘s smooth and big channel ensures full release of stress along pipe products.
7)It has short self-cleaning time when changing pigment colors.
8)It also has high mechanical performance of pipe products and long lifespan of high quality heater.
Applications:
This type of die head system adopts the optimized design to ensure superfine and steady quality of products under low melting temperature.
Specifications:
|
Model |
Pipe range(mm) |
Capacity(kg/h) |
Total power(kw) |
Length of production line(m) |
|
PE63 |
20-63 |
80-150 |
75 |
28 |
|
PE125 |
40-125 |
200-250 |
145 |
29.5 |
|
PE250 |
90-250 |
250-300 |
195 |
42 |
|
PE315 |
110-315 |
300-350 |
220 |
44 |
|
PE400 |
200-400 |
350-500 |
300 |
56 |
|
PE500 |
250-500 |
350-550 |
330 |
56 |
|
PE630 |
280-630 |
700-800 |
480 |
64 |
Competitive Advantage:
1.high quality long use life
2.big discount
3.fast delivery
Our Machines CE certification:
Our Company Service:
Pre-sale service:
•We provide presales service in various forms, for example, making investment budget,manufacturing,planning, etc. so that customers make a reasonable plan with less cost.
•Investment budgeting: We provide services of product profit analysis, recommendation of machine and auxiliary equipment and relevant budgeting, human resources allocation and budgeting.
•Plant Planning: We provide the mounting dimension of the equipment base,design of equipment layout, workshop ventilation, water transmission etc.
• Offer information of peripherals
In-sale service:
• Detailed design of lay-out that is the position of the procession
• Technological information of provided products
• Schedule about design,manufacturing and installation
• Working & Producing progression
•Training course for the technician so that the installation is safe and standard
After-sale service:
•For customers buying our products, we provide them free training so that they can use and maintain the machine independently.
•We will answer customer\'s question on technology in
