2880 Nozzles DX5 Eco Solvent Printer With Two Pintheads / PVC Types

2880 Nozzles DX5 Eco Solvent Printer With Two Pintheads / PVC Types

Quick Detail:

Perfect combination of quality and performance

1.   2 of DX5 Micro Piezo Print heads

2.   70.8’’ (180cm) printing width

3.   10 unique technologies

The efficiency of the A-Starjet 5 printers is twice as that of the competitive printers. They are very suitable for customers who need to make their volume-printings in short time. Not only reducing the investment of printers, but also lowering the cost of maintenance. Well received by professional users.

Description:

1.   Micro Piezo Printing Technology

The DX 5 Micro Piezo print heads can reach resolution of 1440 dpi. Its extremely fine ink droplets are able to fully reflect the rich details of the pictures, and to fulfill the requirement of short viewing range. It suits both water-based dye and eco-solvent pigment ink and widely used in many fields. And it can offer one or two years’ service life.

2.   Variable Ink Droplets Technology

The variable ink droplets technology can project micron grade ink drops of various sizes. Ink drops are between 1.5pl to 21 pl to produce best color results, smooth gradients, and fine details.

3.   Progressive Pass Compensation Technology

The progressive pass compensation technology is used to remove the grinning of white ground or edge overlap ( banding lines), which is usually caused by mechanical inaccuracy, and further improve the yield and save the cost.

4.   Stochastic Ink-droplet Distribution

With the technology of stochastic ink-droplet distribution, some problems caused by nozzle clog, like white strips, can be resolved. Even with 15% nozzle clogged, A-Starjet series printers can still ensure the printing quality.

5.   Multi-heads Arrangement Technology

Dual heads can double the printing speed. In quad-heads mode, CMKY heads can be replaced separately, which can lower the maintenance cost. It can be chosen among single head mode, multi-head quality mode and multi-head performance mode to meet all needs.

     6. New Mechanical Structure

It includes a linear guide drive structure, XY axis coding system, multi-channel ink supply system, heating system on both front and rear platform, media absorption system, and print heads auto-service station. Besides, it also has a paper handling system that can bear loads up to 70kg, and a drying system. The printer weights about 220kg in total and 90% of its components are very durable.

      7. USB 2.0, Bundled with RIP

USB 2.0 interface supports high speed data transmission and collaborative operation. It greatly enhances the printing performance. iPrint 3 RIP software fully complies with ICC color management standard. And it supports automatic image tiling and composition, linear color adjustment and inking management, etc. With the optional PS components, it is also able to process Adobe Postscript files.

      8. Wide Range of Media Compatibility

The height of print head is adjustable between 2 to 5mm, up to 330cm media in width. The printer can use many kinds of compatible ink, like eco-solvent or water-based ink, also pigment or dye ink, as well as sublimation ink. Various of media can be used, including self-adhesive paper, PP, backlit film, canvas, non-woven fabric, chemical fabric, PU leather, micro fibre, leather and etc.

      9. Easy to Maintain & Easy to Use

A-Starjet series printers are designed to meet the high standard of user friendly and operation stability in the industry. Its operability, reliability and durability can compete with any other famous-brand printers in the market.

     10. Higher Performance-cost than any famous-brand printers

A-Starjet series printers have world leading performance and almost half the market price to any famous-brand printers. Furthermore, the printers are able to cover 320cm printing width, and the components are reliable and long lasting. They are designed to satisfy customers with large yield.

Applications:

1.   PVC Type

Flex Banner, Knife Coated Substrate, Double Side Printing Banner PVC, Advertising Cloth, Adhesive Vinyl, One Way Vision, Mesh, Reflective, Banner, Reflective Vinyl.

     2. Eco-solvent Inkjet Media

     Fabric: Flex Banner, Polyester Canvas, Pure Cotton Canvas and so on.

Wall Paper: Wall Paper with PVC on the surface, pure paper Wall Paper, wall paper with fabric on the surface, wall paper with fiber on the surface.
