Round 200CPSI SCR Substrate , Honeycomb Ceramic Monolith Support
- T/T L/C D/P D/A
- 7 days
You May Like
-
100CPSI Diesel Engine SCR Ceramic Substrate For Selective Catalytic Reduction
-
Volatile Organic Compound Ceramic Honeycomb , porous VOC Substrates
-
Ceramic Honeycomb Ceramic Substrate MgO For Exhaust Gas Purifier
-
SiO2 VOC Honey Comb Ceramic Substrate , cellular Cordierite Ceramic
-
Custom Honeycomb Ceramic Substrate , 3 Way Catalytic Converter
-
VOC Honeycomb Ceramic Substrate , porous High Temperature Ceramic
Product Details
| Brand Name | China.Yixing | Place of Origin | China | |
Product Description
Certification:ISO9001 TS/16949
Round 200CPSI SCR Substrate , Honeycomb Ceramic Monolith Support
2. 1.Product use
After coated with catalysts, this product is applied in catalytic converter of diesel vehicle to catalyze, convert and purify the exhaust, making vehicle exhaust reaching standards of Euro IV and Euro V. Technical performance of the product in the leading position in domestic, close to or reach the advanced level of similar foreign products.
2．Overall dimensions standards
|
Item |
Standard values |
Test method |
|
|
Wall thinkness |
100CPSI |
0.45MM±0.03 |
vernier caliper |
|
200CPSI |
0.36MM±0.03 |
vernier caliper |
|
|
300CPSI |
0.28MM±0.03 |
vernier caliper |
|
|
400CPSI |
0.21MM ±0.03 |
vernier caliper |
|
|
Overall dimensions |
OD:＜100MM |
±1.0MM |
vernier caliper |
|
≥100MM |
±1% |
vernier caliper |
|
|
Height:＜150 |
±1.0 |
vernier caliper |
|
|
≥150 |
±1%Height |
vernier caliper |
|
|
Internal crack |
Bright light perspective |
Physical and chemical properties
|
Item |
Standard value |
Test methods |
|
|
chemical component |
Al2O3 |
35.2%±1% |
chemical analysis |
|
SiO2 |
50.9%±1% |
||
|
MgO |
13.9%±1% |
||
|
Cordierite main crystalline phase content |
≥90% |
X-ray diffraction |
|
|
Compressive strength at room temperature |
AA xis |
≥15Mpa |
universal material testing machine |
|
BB xis |
≥2Mpa |
||
|
CC xis |
≥0.15Mpa |
||
|
water absorption |
23-27% |
Gravimetric method |
|
|
softening temperature |
≥1400℃ |
high-temperature electric resistance furnace |
|
|
CTE(800℃) |
≤1.5*10-6/℃ |
thermal dilatometer |
|
|
thermal shock resistance |
450℃ Three times don\'t crack |
air cooling |
Description:
After coated with catalysts, this product is applied in catalytic converter of diesel vehicle to catalyze, convert and purify the exhaust, making vehicle exhaust reaching standards of Euro IV and Euro V. Technical per
