Silver W / O MODEM 10 Pin RJ45 Connector , Right Angle RJ-45 Single Port

Silver W / O MODEM 10 Pin RJ45 Connector , Right Angle RJ-45 Single Port

1.Type: 10 pin rj45 connector

2.TAB direction: Up

3.Port:Single

4.Shieded:YES

5.LEDS:NO

6.EMI finger:NO

7.Length: 21.3mm

Descriptions:

＊ 10/100/1000Base-Tx RJ45 single port 1X1 Right Angle w/o led with side entry

＊ Single port 1X1 Tab-Up RJ45 with internal magnetics

＊ Internal magnetics are 100% electrically tested for HI-POT and functionality

＊ Suitable for CAT5&6 fast Ethernet Cable or better UTP

＊ 350uHminimum OCL with 8mA bias current

＊ High performance for maximum EMI suppression

＊ Minimum 1500Vrms isolation per IEEE 802.3 requirement

＊  ROHS-6 peak wave solder temperature rating 260℃

＊ Operating temperarure range :0℃ to +70℃

＊ Storage temperature range :-40℃ to +85℃

＊ Number of positions:10

＊ Number of contacts loaded:8

＊ Shieded:YES

＊ Rohs compliant

＊ Length:21.3mm

＊ LEDS:NO

＊ EMI fingers:NO

＊ Usage:KRJ-H008WDNL

Applications:

10/100/1000M net card,PCMCIA net card,USB Hub,network switch,router,fiber optic transceivers,optical transceiver,IP phone, PC Board, internet set-top box,internet camera,net bridge,computer,

telecommunication,MODEM,HomePNA,DSL／ADSL and so on.
