Yogurt Lids Aluminum Automatic Die Cutting Machine with with PLC control operation panel
Yogurt Lids Aluminum Automatic Die Cutting Machine with Automatic Embossing
Quick Detail:
Suitable Raw material: Aluminum Foil, Aluminum Coating Paper, Aluminum+Paper, Paper
Suitable Products: All kinds of cup lids, or container lids , such as yogurt cup lids, ice scream lids, medicine inner lids and so on
All Size and shapes are available as per request
Description:
- Unwinding, feeding, embossing, pouching, scrap collecting full automatically
- Machine completed with Channel steel frame structure, safety and stable.
- Embossing available for customers’ request.
- Adapt step motor and photoelectric tracking system to control length
- Scrap collecting system controlled by synchronous motor.
- Built with PLC control operation panel, all operations could on panel.
- Completely with all safety function: length setting; auto counting; auto alarm; auto stop; photoelectric tracking etc. It’s ideal machine for all kinds of cover & lid forming machines.
Applications:
FD-400 aluminum foil die cutting machine and aluminum foil punching machine is developed by continuous improvement of our company according to European advanced technology, mainly used for aluminum foil, paper, film membrane etc materials die cutting into different shapes, such as round, oval, rectangular etc. This ideal machine specially used more for aluminum foil YOGURT LID making.
Specifications:
|
Material Diameter |
≤500mm |
|
Material Width |
≤400mm |
|
Unwinding Diameter |
75mm |
|
Punching Length |
400mm |
|
Punching Width |
400mm |
|
Punching speed |
90-180 times/min |
|
Punching Precision |
0.15 |
|
Punching thickness |
30mic-100mic |
|
Shot number |
3-7 PCS /each time (according to different diameter size) |
|
Embossing Power |
0.8KW/220V |
|
Punching Power |
3.0KW/380V |
|
Total Power |
3.8KW |
|
Machine Size |
2500x1000x1420mm |
|
Weight |
Approx 1700kgs |
Competitive Advantage:
I. We are machines manufacture sale directly
II. High Quality with reasonable price
III. CE Certificate
VI. We provide the technical support all lifelong
FAQ:
1. Q: Are you a manufacturer or trading company?
A: Yes, we are a manufacturer.
2. Q: What certificate do you have?
A: We have ISO ,SGS and CE certificate.
3. Q: How does your factory do regarding quality control?
A: We have a special QC department in charge of products’ quality.
4. Q: How long is the warranty period?
A: All of our products have one year warranty.
5. Q: How much production capacity of your company one year?
A: This depends on your needs.
6. Q: What’s the main market of your company?
A: We have customers all over the world.
7. Q: Where is your factory located?
A: Our factory is located in Zhangjiagang City, Jiangsu Province, China, about 2 hours to Shanghai by car.
8. Q: Can we visit your machine operating in your factory?
A: We have own workshop, and we are enthusiastically looking forward to your visit guidance and
business negotiations!
9. Q: How can we visit there?
A: We offer transportation service when you arrive in Shanghai or Jiangsu Province, China.
