Home > Products > Led Flat Panel Light > 24 W 3014 SMD Led Flat Panel Light 90Lm/w Aluminum For Office , 300 * 600 mm
24 W 3014 SMD Led Flat Panel Light 90Lm/w Aluminum For Office , 300 * 600 mm
- T/T L/C D/P D/A
- 7 days
You May Like
-
6500K SMD 40W LED Panel Light 600 x 600 mm To Replace Grille Lamp
-
Aluminum 40w Led Flat Panel Light High Power , Warm White 3000K Led Ceiling Panels
-
3 Watt Round 90mm Diameter LED Flat Panel Light For Indoor , Recessed Ceiling SMD LED Panel Light
-
LED Flat Panel Light 6 Watt Round 120mm Diameter , Ceiling SMD LED Panel Light
-
60hz 120 9 Watt Led Flat Panel Light 90Lm/w , Recessed SMD Led Lighting Panels
-
Recessed AC 130V 12W Led Flat Panel Ceiling Lights Ultra Thin For Indoor Corridor
Product Details
| Brand Name | R2U | Place of Origin | China | |
| Model Number | R2U - 12003 |
Product Description
Certification:CE & ROHS
24 W 3014 SMD Led Flat Panel Light 90Lm/w Aluminum For Office , 300 * 600 mm
24W 300 * 600 mm LED Flat Panel Light For Office , Aluminum SMD LED Panel Light
Traditional grille is used ordinary fluorescent tube as lighting source, high power consumption, short service life, maintenance costs are high; the LED flat panel light, energy saving and environmental protection, which is designed to replace the traditional grille lamp.
The lamp body of the LED Flat Panel Light is made of high quality aluminum alloy materials . With the big area of the aluminum frame structure and its ultra fast cooling rate , the heat dissipation performance of the lamp is greatly improved . The adopted high efficient SMD LED light source saves energy significantly by its low light decline rate and long service life . The driver part adopts the constant current drive power supply with high accuracy , high efficiency, stable performance and no stroboscopic.
Quick Detail of 24W 300 * 600 mm LED Flat Panel Light For Office , Aluminum SMD LED Panel Light
Dimensions: 300 x 600mm Long lifespan & 3 years warranty Ultra thin 13mm thickness only Power: 24W Light source: SMD 3014 LED CCT: 2800 - 6500KProduct Specifications :
|
Model |
R2U - 12003 |
|
Description |
Recessed Aluminum SMD LED Panel Light |
|
Dimension |
300 x 600 x 13mm |
|
Lighti source |
SMD3014 LED |
|
LED QTY |
200 pieces |
|
Power Consumption |
24W |
|
Input voltage (Driver) |
100V-240V AC /50-60HZ |
|
LED Driver Efficiency |
≥85% |
|
PF |
≥0.95 |
|
Operating temperature |
-40~+60℃ |
|
CCT |
2800k-6500K |
|
Luminous Efficiency |
90Lm/W |
|
Luminous Flux |
2800k-6500lm (±3%) |
|
CRI |
Ra ≥ 80 |
|
Bean-angle |
120 ° |
|
Protection grade |
IP44 |
|
Temperature rising |
< 45 ℃ |
◇Utilizing the high brightness Bridgelux LED chips as light source ;
◇Energy saving , saving 60% of energy than incandescent bulbs ;
◇Encapsulated by the special craft make it durable , good heat dissipation by ravines surface structure, service life can reach 50000 hours ;
◇Green environmental protection materials . No ultraviolet , infrared , thermal radiation and mercury pollution ;
◇As a kind of cold light source , LED lights will not make the goods for produce fade phenomenon ;
◇Using high-quality reflectors, downy light , High light efficiency ;
◇High CRI make the light true and clear and have different color temp ;
◇Fast response , no stroboscopic , low glare , total luminous flux output reached when the lights on ;
◇Solid-state light source , strong shock resistance , convenient for transportation and installation , high safety ;
◇Luminous directionality is strong , easy to control the light , effectively improve the efficiency of the lighting system ;
◇Fashion modeling , close to customer needs , blend in more elements of science and technology and humanized design .
★Usage Instruction: Before installation , please read carefully the product specification to make sure the operating environment conforming to the conditions ; Turn off the switch before connecting to the power ; Lamps and lanterns should be installed by a qualified electrician , wiring connectContact Us
