CNC Industrial Shaft Gear Deburring Machine , 60W , 2800rpm
- 0 Kilogram / Kilograms per Month
- T/T L/C D/P D/A
- 7 days
Product Details
Brand Name: | JJR | Place of Origin: | China | Model Number: | YE9320A |
Product Description
Certification:ISO9000
CNC Industrial Shaft Gear Deburring Machine , 60W , 2800rpm
Quick Detail:
The gear tooth deburring machine is a semi-automatic full-enclosed high-efficiency machine for deburring the end faces of the disc-type gears or shaft gears used in gear boxes of automobiles. One end face or two end faces of the gear can be deburred (with an imported deburring tool) on this machine. According to the machining characteristics, the machines can be divided into the shaft gear deburring machines and the disc-type gear beburring machines. The workpiece is rotated and deburred by means of the engagement of the cutter and the workpiece, and at the same time the workpiece drives the cutter rotating to remove the burs on the tooth ends.
Description:
The gear tooth deburring machines are classified into YE9320A, YE9340 and YE9340A according to their working
range. Two sets of deburring mechanisms with separate controls are equipped on the YE9340A machines,
which are suitable for workpieces of different kinds and two teeth of a shaft gear can be deburred and burrs on
the end face can be removed simultaneously.
Specifications:
Model Name |
YE9340 |
|
Max. outside diameter of work |
mm |
400 |
Min. outside diameter of work |
mm |
30 |
Max. module of work |
mm |
8 |
Min. module of work |
mm |
1.5 |
Machining speed |
s/pc |
30 |
Speed of cutter spindle |
rpm |
63 |
Distance between cutter spindle and center of two centers |
mm |
115~250 |
Distance between two centers |
mm |
520 |
Infeed of saddle |
mm |
0~12 |
Motor of cutter spindle |
Kw, rpm |
1.5, 1400 |
Hydraulic motor |
Kw, rpm |
1.1, 1400 |
Motor for lubrication |
W, rpm |
60, 2800 |
Overall dimensions (L×W×H) |
mm |
2225×1280×1928 |
Weight |
kg |
3600 |
Company Profile:
Heng Yong company gathered many experienced experts. This team is lead by people have over decades of experience, and filled with young, energetic engineers. With strong research and developing ability, our company put extraordinary effort on developing complete sets of gear machinery. Now we are able to provide our customer the main products as follows: Gear Shapers, Straight Bevel Gear Generators, Spiral Bevel Gear Generators, Spiral Bevel Gear Grinders, Hypoid Gear Testers, Gear Lappers, Gear Quenching Press, Gear Chamfering Machines, Gear Hobbers, Honing Machines, Vertical & Horizontal Machining Centers, Special Precision Speed Reducers, Roll Stander for Seamless Tube Stretch Reducing Mill, Gear Coupling Family, Low Drive Devices and Environmental Protective Equipment of 16 kinds, more than 30 families, and more than 150 types and specifications. The company focus on developing heavy-duty, large CNC gear machinery, which are urgently needed by the government and makes industrialize as soon as possible, provide a great variety of advanced gear machinery to the market. The company is using the leading 3D designing software for developing and designing. The company combines producing with research and development by Cooperating with TIANJIN University and other colleges fo
