EPS Panel Dormitory Prefabricated House , Sea Container House for Living

Delivery Time:20-25days after receipt of deposit
Certification:CE/ISO

EPS Panel Dormitory Prefabricated House , Sea Container House for Living

Description:

Good water-proof and insulation Wind load: 220km/h Earthquake resistance Quick installation Long life span

Roof

1. Steel sheet roof--- with 50mm steel color sandwich panel+75mm glass wool

2. New design can prevent the water flow back

3. Water proof, leakage proof.

Bottom:

1. Designed as a whole welded steel structure frame with high strength.

2. Can fit the load of living and working.

3. Can make the base insulation according to the requirement. Temperature can adjust to meet the living requirement.

Door system:

 Aluminum frame –design only for SEM.

 Color-steel sandwich panel door(50mm).

Window: Plastic steelaluminum window with fly screen- SEM designed specially

Compressive project:

1. roof insulation: 50mmEPS +75mm glass wool
2. wall slot: 0.5mm color steel plate blending
3. outside corner cover: 0.5mm color steel plate blending
4. inside cover: PVC cover

Note:

1. The thickness of color-steel sandwich panel can be chosen by customers.

2. Window: Plastic steel window with fly screen Floorboard

3. PVC covering floor or laminate flooring (can be chosen by customers)

Application:

Our houses are widely used for accommodation, temporary offices, villas, warehouses, schools, shelters, guarding rooms, showrooms, bus stations, storage houses and so on.

Competitive Advantage:

1.  Good in quality and beautiful in design.

2.  We can offer the installation guide drawings.

3.  If it is the large quantity, we can send experienced engineer to guide the installation.

4.  High heat-proof quality, good sound insulation function.

5.  Wind and earthquake resistance

6.  The span life of this house is over 20 years.

Specifications:

Item	details	specification
steel frame	corner fitting	standard container fitting
base frame	3.0mm steel plate
secondary frame	2.5mm steel plate
stand column	2.5mm steel plate
roof frame	2.5mm steel plate
Forklift slot	3.0mm steel plate
strength plate	6mm steel plate
panel	wall panel	50mmEPS sandwich panel
wall panel	50mmEPS sandwich panel
ceiling plate	50mmEPS sandwich panel
surface plate	0.5mm color steel plate
base	base floor	1220*2440 plywood floor
surface floor	pvc floor
door and window	door	aluminum sandwich panel door
window	aluminum sliding window 0.9m*1.2m
window	aluminum fixed window 0.9m*0.6m
window cladding	aluminum
compressive project	roof insulation	75mm glass wool
wall slot	0.8mm stainless blending
