Energy Saving 200w LED High Power Flood Lights For Public Lighting

Energy Saving   200w LED High Power  Flood Lights For Public Lighting

Quick Detail:

1. CREE chip and Meanwell driver

2. Patented thermal management(Mutiple LED layout design and ultra Fold-Fin heatsink technical design)

3. Extremely light weight and easy installation

4. up to 3 Years warranty

5. CE ROHS ETL marked

Description:

General Information

• Unique fin aluminium heatsink greatly reduce product weight and guarantee the safety usage,

   as well as to avoid the material wastage comparing with conventional die-cast or extrusion heatsinks.

• By increasing the number of fins to enlarge the area of heat dissipation and air flow,

 this new heatsink significantly increase the efficiency of  thermal conduction with less material usage and more saving on energy. It is the best solution of LED flood lights

Key Features

•  Proprietary thermal management design to ensure low LED junction temperature

•  Extremely light weight to enhance the safety use and installation

•  Full product portfolio up to 600W, with luminous flux of up to 60,000 lm

•  LEDs from Philips Lumileds, Cree or Edison, with Meanwell drivers, up to 5 years warranty

•  Available in various optical beam profiles, including 15° to 60° round, 65°×135° symmetric rectangular, and 85°×135° asymmetric rectangular

Design Innovation

•  Air ventilation design and distributed heat source

    - Very effective air flow across the heatsink
    - Bring the heat away by natural convection
    - Largely spread the heat source and thus lower temperature

•  Fold-Fin Heatsink (FFH) Technology

    - Formed by Aluminum sheet metals
    - Fully automated production
    - Resulting in large surface area and less weight

•  Flexible Optics and Mounting Design

    - Available in various optics (round and rectangular profiles)
    - Easy mounting bracket design

Specifications:
