Micro White Multifunction USB Cable 30 Pin For IPhone 4 / Samsung / IPod
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
AIBUSI
Place of Origin:
China
Model Number:
ABS-C19
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
3 In One Charging Multifunction USB Cable For Samsung Galaxy S3 With Apple 30 PinNegotiableMOQ: 1 Piece -
Colorful 1M 4 in 1 Multifunction USB Cable / Micro USB Charger Data CableNegotiableMOQ: 1 Set
-
White Powered 4 in 1 Micro USB Charger Cable , Iphone Lightning To USB CableNegotiableMOQ: 1 Piece
-
TPE Noodle Flat Fast Charging Multifunction USB Cable For SAMSUNg Galaxy S3NegotiableMOQ: 1 Piece
-
IPhone 5S / 4 3 In 1 USB Charging Cable / SAMSUNG Micro Powered Data Cable WhiteNegotiableMOQ: 1 Piece
Brand Name
AIBUSI
Place of Origin
China
Model Number
ABS-C19
Certification:CE,ROHS, FCC
Micro White Multifunction USB Cable 30 Pin For iPhone 4 / Samsung / iPod
Quick Detail:
|
Name |
2 in 1 charge &sync usb cable for iphone4S/Samsung/Blackberry |
Brand Name |
ABS-C18 |
|
Color |
white,black,yellow, green,blue.Pink |
Feature |
USB AM to iphone4s+iphone5/5S TPE Materieal, With DATA+Charge Func,in each port |
|
Place of origin |
Guang dong china (mainland) |
Certificate |
CE,RoHS, FCC |
Production Introductions:
With Micro and apple 30 pin connectors,it is compatible with iphone4,ipod,iphone4s and Samsung using Micro usb jack.Production Description:
1,Sync data or charging 2,Can be through the Dock direct or indirect. 3,Connect to the iphone4/4s ,Samsung ,blackberry and most mobile phones etc to computer USB port, in order to achieve efficient sync data transmission and the charging function. 4,100% brand new & high quality 5, Wide-body wire, not knot, convenient use 6, Many colors, more fashion, more personalityWire rod Description:
1. No.of cond:4 Conductors
2. Conductor 1
a, Material: Enameled Copper Wire 1 UEW
b, Construction: 0.06mm/18 strands
c, Fillers: Nylon Silk White 250D
3. Conductor 2
a, Material: Enameled Copper Wire 1 UEW
b, Construction: 0.06mm/30 strands
c, Fillers: Nylon Silk White 250D
4. Jacket
a, Material: NON Migration TPE Dull Surface
b, Diameter:2.0*5.5mm
c, Way of Extrusion :Solid
| Construction | ||
| ITEM | DESCRIPTION | |
| No.of Cond | 4 Conductors | |
| Conductor(1) | Material/Color | Enameled Copper Wire 1 UEW / According to the picture ( 1 , 4 ) |
| Construction | 0.06 mm / 18 strands | |
| Fillers | Nylon Silk White 250D | |
| Conductor(2) | Material/Color | Enameled Copper Wire 1 UEW / According to the picture ( 2 , 3 ) |
| Construction | 0.06 mm / 30 strands | |
| Fillers | Nylon Silk White 250D | |
| Jacket | Material/Color | NON Migration TPE Pass ROHS/Green Dull Surface |
| Diameter | 2.0 * 5.5mm | |
| Way of Extrusion | Solid |
| DESCRIPTION:［(0.06/18+250D)*2C+(0.06/30+250D)*2C］*1F | |
| TITLE: 2.0 * 5.5 4C TPE | |
| NO | Conductor |
| 1 | Blue |
| 2 | Nature |
| 3 | Red |
| 4 | Green |
Characterisitcs:
Conductor Resistance:Resistance shall not exceed 0.6 ohms/m Withsand Voltage test: No Breaking (250 VAC/1min,between two wires) Insulation Resistance:Shall not less than 10 Mohms·m(250 VAC/1min,between two wires) NON Migration Test: N0 Trace (500g;60℃;ABS;48H)| ITEM | Condition | SPEC | ||||||
| Conductor Resistance | ￣ |
Resistance shall not exceed 0.6 ohms/m |
||||||
| Withstand Voltage Test | 250 VAC / 1 min , between two wires | No Breaking | ||||||
| Insulation Resistance | 250 VAC / 1 min , between two wires | Shall not less than 10 Mohms·m | ||||||
| NON Migration Test | 500g ; 60℃; ABS ; 48H | NO Trace | ||||||
| Bending Test | Load | Angle | Diameter | Jig | Bend Radius | Frequency | Requirement | Not to cut off Wire |
| 200g | ±90 | ￣ | √ | R25.4 | 30/min | min:3000 | ||
| Envirommental Protection | ROHS | Accord with |
