Thin Wall BKW NBK GBK Carbon Steel Tubing ASTM A513 , ERW Mechanical Roundn Steel Tubes
Quick Detail:
Standard: ASTM A513
Size:(mm)
Out Dimensions: 6mm - 350mm
Wall Thickness: 0.8mm - 35mm
Length: Fixed(6m,9m,12,24m) or normal length(5-12m)
Description:
The ASTM A513 is a kind of seamless steel pipes and is called Electric-Resistance-Welded Carbon Steel Pipe. This seamless steel pipe has a round section shape.
The ASTM A513 steel pipe has some sorts , for example:ASTM A513 1010,ASTM A513 1020,ASTM A513 1025, ect.
ASTM A513 seamless steel pipe is widely used in Machinery and Automobile.
As an experienced China seamless steel pipe manufacturer, we manufacture our steel pipes according to ISO9001-2000, PED, API, TS16949,KR,LR so that we can be assure of the quality of steel pipes. Besides, we implemented the following inspections and tests: Chemical Composition Inspection, Mechanical Properties Test(Tensile Strength, Yield Strength, Elongation, Flaring, Flattening, Bending, Hardness, Impact Test), Surface and Dimension Test.
Main Steel Grade:
Q195 → Grade B, SS330,SPHC, S185
Q215 → Grade C,CS Type B,SS330, SPHC
Q235 → Grade D,SS400,S235JR,S235JO,S235J2
ASTM A178 Grade A, C, D
ASTM A179 Grade A, C, D
ASTM A192
ASTM A210 GradeA-1, C
BS3059-Ⅰ 320 CFS
BS3059-Ⅱ 360, 440, 243, 620-460, 622-490, S1, S2, TC1, TC2
EN10216-1 P195TR1/TR2, P235TR1/TR2, P265TR1/TR2
EN10216-2 P195GH, P235GH, P265GH, TC1, TC2
DIN17175 ST35.8, ST45.8
DIN1629 ST37.0, ST44.0, ST50.0
JIS G3454 STPG370, STPG410
JIS G3461 STB340, STB410, STB440
GB5310 20G, 15MoG, 12CrMoG, 12Cr2MoG, 15CrMoG, 12Cr1MoVG, 12Cr2MoWVTiB
GB9948 10, 20, 12CrMo, 15CMo
GB3087 10, 20
(Or per customers’ requirement.)
Packing:
Beveled/black painting/ plastic caps/ in bundles/ steel strips/ wooden protection
Inspection and Test:
Chemical Composition Inspection, Mechanical Properties Test(Tensile Strength, Yield Strength,Elongation, Flaring, Flattening, Bending, Hardness, Impact Test),Surface and Dimension Test,Nodestructive Test, Hydrostatic Test
Surface treatment:
Oil-dip, Varnish, Passivation, Phosphating, Shot Blasting
Mark:
Marking or mechanical stamp on each piece of tube to be confirmed or as requested
Method of manufacture:
Electric-Resistance-Welded
Delivery condition:
The tubes shall be supplied in one of the following delivery conditions
a) Cold finished/hard (cold finished as drawn): BK;
b) Cold finished/soft (lightly cold worked): BKW
c) Annealed: GBK
d) Annealed (including de-scaling): GZF;
e) Normalized: NBK
f) Normalized (including de-scaling): NZF.
Related Steel Grade Chemical composition Limits(%) :
|
Grade |
Carbon |
Manganese |
Phosphorus (Max) |
Sulfur (max) |
Silicon |
Nickel |
chromium |
Molybdenum |
|
1010 |
0.08~0.03 |
0.30~0.60 |
0.035 |
0.035 |
-- |
-- |
-- |
-- |
|
1020 |
0.18~0.23 |
0.30~0.60 |
0.035 |
0.035 |
-- |
-- |
-- |
-- |
|
1025 |
0.22~0.28 |
0.30~0.60 |
0.035 |
0.035 |
-- |
-- |
-- |
-- |
|
1035 |
