Home > Products > Bridgelux COB LED > 8 Watt 900Lm Bridgelux COB LED 130 Degree 80 CRI With CE Approved
8 Watt 900Lm Bridgelux COB LED 130 Degree 80 CRI With CE Approved
- T/T L/C D/P D/A
- 7 days
You May Like
-
RoHS Approved LED High Bay Light 150W For Bridges Lighting
-
50W - 180W Highways Bridgelux LED High Bay Light 10000Lm With CE Approved
-
Factories Lighting 12000Lm High Bay Light , 120W Energy Saving Bridgelux LED Source
-
Epistar 100 Lm/W 70W Integrated LED Module 120 Beam Angle
-
Bridgelux Chip 14W Street Light Module 70 CRI 2000 Lumen
-
14W Long Life Outdoor LED Street Lights Module 100Lm/W Natural White
Product Details
| Brand Name | Lepower | Place of Origin | China | |
| Model Number | LY-IHN30801B4545 |
Product Description
Certification:CE|RoHS
High efficiency 900lm 8W cob led module with factory patent
Quick Detail:
8W power consumption COB package, high light efficiency Bridgelux led chip customized 24-27V, 320mA, up to 100lm/W,Ra>80 Size: D13.8mm*L21mm Warm white/Natural white/Cool white optional Match with Lepower exclusive lens, light transmittance rate can be up to 92% CE, RoHS, EN62471 compliance, LM-80 under testing Flexible solutions for various kinds of product. 2 years warranty8 Watt 900Lm Bridgelux COB LED 130 degree 80 CRI With CE Approved
Description:
Exclusive package design, national patent approved. NX3 led series, 4-12W different power customized Super high lumens light source Several led chips available, easy selection with your goal. Different beam angle lens available, easy control your lightApplications:
Spotlight Track light Down light Stage light High bay lightSpecifications:
Dimension
Electrical/Optical Characteristics (At TA=25°C)
|
Parameter |
Symbol |
Conditions |
Min. |
Avg. |
Max. |
Units |
|
Luminous Flux |
Φ |
IF=320mA |
800 |
-- |
900 |
lm |
|
Color Rendering Index |
CRI |
IF=320mA |
70-- |
75 |
Ra |
|
|
Color Temperature/ Color coordinates |
CCT |
IF=320mA |
2800 |
-- |
3000 |
K |
|
Forward Voltage |
VF |
IF=320mA |
24 |
-- |
27 |
V |
|
Luminous efficiency |
Φ |
IF=320mA |
90 |
-- |
100 |
Lm/W |
|
Thermal Resistance Junction To Board |
RΘJ-B |
IF=320mA |
− − |
2 |
− − |
°C/W |
|
Reverse Current |
IR |
VR=17V |
− − |
− − |
2 |
μA |
|
Viewing Angle [1] |
2Θ1/2 |
IF=320mA |
− − |
130 |
− − |
Deg |
Absolute Maximum Rating(At TA=25°C)
|
Parameter |
Symbol |
Ratings |
Units |
|
Power Dissipation |
PD |
8 |
W |
|
Continuous Forwar |
