Home > Products > Braided Steel Wire Rope > Anti twist 18 Strands Breakage load 372kN Braided Steel Wire Rope for Overhead Transmission Line 22m
Anti twist 18 Strands Breakage load 372kN Braided Steel Wire Rope for Overhead Transmission Line 22m
- T/T L/C D/P D/A
- 7 days
You May Like
-
Anti Twisted Galvanized Braided Steel Wire Rope for Overhead Cable Stringing 28mm
-
30mm 658kN T29 Non twisting Braided Galvanized Steel Wire Rope Cable Stringing Rope
-
9mm 55kN Anti twisted Braided Steel Wire Rope for Line Stringing 6 Squares 12 Strands
-
24mm Anti-twisting Breaking Load 389kN 18 Strands Braided Steel Wire Rope Line Stringing Engineering
-
28mm 480kN 12 Strands Anti twisted Galvanized Braided Steel Wire Rope Overhead Conductor Stringing
-
30mm 540kN T29 Anti twisting Braided Galvanized Steel Wire Rope Line Stringing Engineering
Product Details
| Brand Name | Boyu | Place of Origin | China | |
| Model Number | YL22-18xT25 |
Product Description
Certification:ISO9001
22mm Anti-twisting 18 Strands Breakage load 372kN Braided Steel Wire Rope Overhead Transmission Line Stringing
Quick details:
Transmission Line Stringing Accessories Anti-twisting Braided Steel Wire Rope Normal Diameter: 22mm Breakage load: 372kN Size available: 9~30mm 6 Squares 18 Strands Length: 500m Reel diameter: 1400mm
Description
Anti-twisting braided wire rope with high strength hot dip galvanized steel quality air processed by the special process of special woven rope line. It has high strength, good flexibility, corrosion rust-proof, not to fight the golden hook, and difficult to tie, long life and so on. Tension applied to pay-off power lines construction, lifting equipment with the balance shaft and the tail rope of mine, port and other major lift crane wire rope does not rotate when the required place.
|
Item no. |
Normal Diameter (mm) |
Structure |
Ref. Weight (kg/m) |
Breakage tension(kN) |
||
|
Rope structure |
||||||
|
1x19 |
1x19W |
T25 T29 |
||||
|
YL9-12x19 |
10 |
6 Squares 12 Strands |
0.297 |
50 |
55 |
|
|
YL11-12x19 |
11 |
6 Squares 12 Strands |
0.480 |
70.5 |
80 |
|
|
YL13-12x19 |
13 |
6 Squares 12 Strands |
0.630 |
105 |
120 |
|
|
YL15-12x19 |
15 |
6 Squares 12 Strands |
0.925 |
140 |
158 |
|
|
YL18-12x19 |
18 |
6 Squares 12 Strands |
1.150 |
185 |
210 |
|
|
YL20-12x19 |
20 |
6 Squares 12 Strands |
1.320 |
250 |
||
|
YL22-12XT25 |
22 |
6 Squares 12 Strands |
1.822 |
320 |
||
|
YL24-12xT25 |
24 |
6 Squares 12 Strands |
2.034 |
360 |
||
|
YL28-12xT29 |
28 |
6 Squares 12 Strands |
2.882 |
480 |
||
|
YL30-12xT29 |
30 |
6 Squares 12 Strands |
3.120 |
540 |
||
|
YL20-18x19 |
20 |
6 Squares 18 Strands |
1.598 |
280 |
300 |
|
|
YL22-18XT25 |
22 |
