Home > Products > Cardboard Box Making Machine > Automatice Rotary Cardboard Box Making Machine With Pneumatic Brake
Automatice Rotary Cardboard Box Making Machine With Pneumatic Brake
- T/T L/C D/P D/A
- 7 days
You May Like
-
Corrugated Cardboard Box Making Machine Creasing / Slitting CE ISO
-
Die Cutting Corrugated Cardboard Box Making Machine Pneumatic With Stacker
-
Automatic Cardboard Box Making Machine , Slotting Printing Machinery
-
Paperboard Carton Box Making Machine , Automatic Folder Gluer
-
Semi Automatic Carton Box Making Machine , Manual Carton Stapler
-
Quick Gluer Carton Box Making Machine Semi-Auto For Corrugated Paper
Product Details
| Brand Name | XINTIAN | Place of Origin | China | |
| Model Number | XT-L |
Product Description
Certification:CE,ISO9001:2000
Automatice Rotary Cardboard Box Making Machine With Pneumatic Brake
Packaging Type: Pallet
Driven Type: Electric
Automatic Grade: Semi automatic
Voltage:380V 50HZ
Power:18KW
Application: To make all kinds of corrugated carton box
Main Technical Parameter
SERIAL | WYAZS NAME | UNIT | WYAZS |
2500×2800 |
|||
1 | Inboard width | Mm | 3200 |
2 | verage size | Mm | 2500×3100 |
3 | verage size | Mm | 600×500 |
4 | Max.printing area | Mm2 | 2450×2800 |
5 | Thickness of printing plate | Mm | 6 |
6 | Max.speed | Pieces/min | 50 |
7 | Power of main motor | Kw | 11 |
8 | Size for whole machine | Mm | 6000×4200×2500 |
9 | weight | T | 15 |
Functions and Features:
1. Chain feeding model can ensure that the bent board paper be smoothly sent due to the elastic pressing
plate at the front of feeding system.
2. Motorized detachment and combination; pneumatic locking and loosening of printing units; automatic ink
distribution and pneumatic brake separation orientation.
3. Printing and slotting phase is adjusted by planetary-gear electric phase, shown by digit.
4. Whole machine uses the gear pumping automatic lubrication.
5. Ink roller and printing pressing roller are connected by cross slide to ensure steady transmission.
6. All axles and rollers are plated with rigid chrome and grinded surface.
7. The whole machine adopts the electric parts from CHINT and DELIXI; Whole machine bearing is from the
Harbine Bearing Group.
8. Option of printing slitting and creasing or printing slotting.
