ATV GT200ST-B/Quad Bike

ATV/EEC ATV/Racing ATV/ 200cc ATV/Quad Bike

ATV OF JAPAN BRAND AND HIGH QUALITY-

MODEL NO.: GT200ST-B --------EEC certificate for two persons

-

-

SPECIFICATION

-

ENGINE

Type:- single cylinder, water-cooling, 4-stroke

Cylinder size:- 63.5 x 62.2mm

Displacement:- 197ml

Ignition mode:- CDI

Compression proportion:- 9.2: 1

Power:- -9.5KW/7500r/mi

Max. torque:- 12.1N.m / 6,000rpm

Engine oil: -0.9L

Lubrication:- press splash

Start mode:- Electric recoil backup

-

CHASIS

Transmission mode:- chain

Transmission:- 4 gears with one reverse gear, manual clutch

Max. speed:- ≥70km/h

Power source:- 12V, 9Ah

Parking trig:- mechanical lock

Break type (F/R):-- disc / disc

Front hanging:- double arm-swing

Rear hanging:- integral

-

DIMENSION

Wheelbase:- 1230mm

Front wheels:- -21x 7-10

Rear wheels: -20 x 10-9

Height of seats:- -850mm

Dry weight: -167kg

Load capacity:- 105kg

Climbing degree:- ≥20°

Min. ground clearance:- 130mm

Min. turning radius:- 2,650mm

Max. number of riders:- 2

Fuel tank capacity:- 5.5L

-

PACKAGING

Product dimensions:- 1740×1110×1110mm

Carton dimensions:- 1470×850×870mm

product color:- red/yellow/blue/green/camouflage

Conveyance: -Qty/20 GP: 20 units

----- ------- ----- -Qty/40 GP: 44 units

----- ------- ----- -Qty/40 HQ: 66 units
