3.7V 3000mAh Li-ion Temperature Adjustable Heated Vest Li-ion Battery Packs

Model No.

LX-DRF03

Nominal Voltage

3.7v

Working Voltage

3V-4.2V

Nominal Capacity

3000mAh

Charge Cut-off Voltage

4.2v

Charge Current

200mA~1000mA

Standby Current

≤15μA

Max. Output Power

8W MAX

Operating Efficiency

≥99%

Loading Resistance

2Ω-200Ω

Charge Method

CC/CV Constant Current/Constant

Charge Temperature

0℃—40℃

Discharge Temperature

-20℃～ +60℃

Charge Duration

1-3hrs(Standard)

Cycle Life Time

Above 500 cycles

Internal Impedance

PCB Internal Impedance<50mΩ;

Battery Internal Impedance <150mΩ

LED Display

3-heat settings, capacity level indication

Output Terminal

DC3.5*1.35*7mm

Usage

For heated vests, heated seat cushions, etc.

Battery Size

65*48*15mm

Weight

90g

Color

white, black, red, pink, blue, brown, etc.

Certificates

CE, FCC, ROHS

Lead Time for Sample

3~7 days

Lead Time for Bulk Order

7~15 days

Remaining Capacity

LED

90~100%

●

30%～90%

●

0%～30%

●

Output Power

LED

91%

●

75%

●

40%

●

Off

○
