Automatic High Purificaition Residential Air Curtain Cold Rolled Steel , 1500x240x240mm
Quick Detail:
1.Name: FM30 Air Curtain
2. Brand Name: YIJING
3. Material: All full set Stainless Steel SUS304,Cold Rolled Steel.
4. Feature: Automatic Control
5. Outside dimension: 1500×240×240 (mm)
6. Certificates: CE,ISO
Description:
The FM30 air curtain is a product with a novel arc design. The adopted high efficiency PTC heating element is developed by integrating the latest technology from abroad. It is safe and has the features of no open fire, long lifetime and high durability. Meanwhile, the product is equipped with contactor and can achieve free switching between cold and hot air. The control box for rated current and the manual control switch device can be available. The mounting height within 3m is proper for the product. Several sets of the product can be assembled together for matching with the width of door. Our air curtain is very fit for use in hospital, shopping mall, restaurant and others.
Specifications
|
Model |
Power (W) |
Air Speed at Air Outlet (m/s) |
Air Volume (m3/min) |
Mounting Height |
Noise (dB) |
Outside Dimension (mm) |
Weight (kg) |
|
YJFM30-60 |
80 |
10-13 |
35-40 |
Within 3m |
≤60 |
600×240×240 |
14 |
|
YJFM30-90 |
120 |
10-13 |
40-45 |
≤62 |
900×240×240 |
18 |
|
|
YJFM30-100 |
180 |
10-13 |
42-47 |
≤63 |
1000×240×240 |
20 |
|
|
YJFM30-120 |
180 |
10-13 |
45-50 |
≤64 |
1200×240×240 |
21 |
|
|
YJFM30-150 |
250 |
10-13 |
50-55 |
≤66 |
1500×240×240 |
25 |
|
|
YJFM30-180 |
370 |
10-15 |
55-65 |
≤68 |
1800×240×240 |
30 |
Features:
This series of air curtains has six kinds with the models of YJFM30-60, YJFM30-90, YJFM30-100, YJFM30-120, YJFM30-150 and YJFM30-180. They are different in dimension, power and air volume and can meet the needs of customers fully. The YJFM30-60 product has the smallest size and weight. It can be installed easily and flexibly. Meanwhile, it can provide the air volume of 35 to 40m3/min and has low working noise which is no greater than 60dB. The YJFM30-180 product has the largest power of 370W and can provide the air volume up to 55 to 65m3/min. It has the largest size of 1800×240×240mm and needs enough space for installation.
As an experienced air curtain manufacturer in China, our company provides a wide range of products that includes double person horizontal laminar flow clean bench, 100 class clean cabinet, clean room HEPA filter, and more.
Why to choose YIJING Brand Air Curtain?
1) 15+ years experience.
2) 1000 + successful cleanroom projects completed.
3) Turnkey In-House Cleanroom Engineering and Design Capabilities.
