110Kw Cooling Capacity R134A Refrigerant Air Cooled Screw Chiller With 7C Water Outlet

110Kw Cooling Capacity  R134A Refrigerant Air Cooled Screw Chiller With 7C Water Outlet

Features:

1.Twin screw compressors of world famous brand is adopted, with high efficiency, low noise level, less wearing and long operation time.

2.The unit is of high performance as they are made of the condensers and evaporators of grooved copper pipes, and high quality components, by specialized process.

3.The unit is easy to operate, and friendly interfaced, as they adopt leading brand PLC, 64K color touch screen and other control elements.

4.The energy saving for Multi-capacity regulation resulted in cost cut down for operation and maintenance.


Components

RIOU industrial brine chiller mainly consists of compressor,  control panel, condenser and evaporator. You can choose the type and brand of these components yourself. Or we may help you according to your needs.

1. Compressor

RIOU uses the famous compressor, like Bizer, Copeland, Danfoss, Sanyo, Taiwan Hanbell and Taiwan Fu Sheng, to ensure the quality. RIOU believes that diversified choices can meet most of the clients\' needs.

2. Control Panel

Normally, scroll chiller is equipped key control panel with LED display and screw chiller is controlled by touch screen (human-machine interface). You can choose Punp (usual), Siemens or Mitsubishi brand. According to your needs, the chiller can be long-range controlled.

4. Condenser

RIOU industrial brine chiller normally adopts shell and tube type condenser. The refrigerant will be cooled down here by the water cooling tower. That’s the reason why water cooled chiller need water cooling tower.

As the water cooled chiller doesn’t need fan, it’ll not influence the surrounding temperature. Besides, the surrounding temperature impact on the water cooled chiller is small.

5. Evaporator

for the brine chiller,you can choose “Ti Coil Tube” or “Heat Exchanger” type. which are both anti-corrosive.

6. Water Pump

For brine chiller,it needs stainless steel pump.


7. Water Tank

The chiller usually is equipped a water tank inside. Besides, RIOU can provide different capacity of water tanks inside or outside the chiller for clients to keep the liquid temperature in the water tank. The material of water tank is 304# stainless steel in usual.

8. Others

Danfoss electromagnetic valve, Emerson filter, LG contactor and LG thermal relay.

Model:RO-160A

1.Cooling Capacity(Ton/H):110(7C outlet temperature)

2.Power Supply:3N-380V-50Hz

3.Input Power(KW):120

4.Energy Control: 100%-75%-50%-25%-0%

5.Compressor Power:Semi-hermetic Screw Type

               Power(KW):116

               Start Way:Y-time

6.Refrigerant: R134A

           Charge(KG):96

           Flow Control: expansion valve

7.Evaporator: Shell and Tubes

           Cold Water Flow(m3/h):88

           Water Resistance(Kpa):53

            Pipe Size(mm):100

8.Condenser: Fin type

            Air Volume(m3/h): 200000

9.Temperature Control Range(℃): 7—normal degree

10.Running Current(A):198

11.Net Weight(KG):3500

12.Running Weight(KG):3800

13.Dimension L*D*H(mm):4500×2260×2300

Remarks:The cooling capacity is calculated according to condensing temperature 50℃, evaporator temperature

2℃ .

 To give you our best offer one time,please indicate:
1.What is the cooling capacity you need?
2.Air cooled or water cooled?As you see,water cooled need a separated cooling tower .
3.What is the outlet water/glycol/seawater temp you need?
4.What is the power supply?
5.Do you need water pump,water tank together?
6.Is there any special requirement for the refrigerant?R22,R134A,R407C,R404A or other?

Welcome to contact  vivian@rozl.com!
