Burnt scars, Skin renewing Medical Fractional Co2 Laser , RF Carbon Dioxide Equipment

Delivery Time:3~7 working days
Certification:CE Certificate, ISO9001, SGS,BV

Burnt scars, Skin renewing Medical Fractional Co2 Laser , RF Carbon Dioxide Equipment

Specifications:

Laser Type	RF Driver Fractional CO2 Laser
wavelength	10.6μm,  far-infrared laser
Pulsed radiofrequency	0.530 W
Hyper-pulse	1.Max power: 120W 2.Pulse width:200 to 500μs is optional
Pulse	1. Average power: 0.5-20W 2. Pulse frequency:33.3 Hz
Scan Graphics	Square,  rectangle,  round or customized graphics
Dot quantity	400 dots at most
Working state	Hyper-pulsed mode
Scan mode	Sequence scan or Random scan.
Pulse energy	10mj to 100mj is optional for each dot.
Technical specification
Laser apparatus	Sealedoff laser device stimulated by direct current
Condenser focus	f=100mm
Beam divergence angle	0.3 mrad
Spot size	Min 0.2mm at the focus
Radiation time	0.01 1 sec
Interval time	0.01 1 sec
Aiming beam	Less than 2mW, 635nm red semiconductor laser
Beam transport device	Articulated arm with six segments and balance weight
Power supply	AC 220V±10% 50Hz AC 110V±10% 60Hz

Applications:

Skin renewing and resurfacing Wrinkle removal, skin tightening Acne and acne scar removal Smooth burnt scars and surgery scars, Remove intractable chloasmas and pigmentation Sun damage recovery.

Work Theory of Fractional CO2 Laser:


CO2 Fractional laser treatment is a brand new laser rejuvenation technology. It changes the physical medium and emission method of current laser technology by focusing tremendous optimized energy. Through Laser Emitter. The micropulsed laser beam shooting on target skin in nano level to achieve a controllable and precise treatment. The dimension of shooting area only can be measured in nanometer, which is precise enough for operator to control and adjust the treated depth and layer according to the clinical diagnosis. The energy of CO2 Fractional laser is even and steady, its focused energy aims only at target tissue without any injury to surroundings. During the scan treatment, surrounding tissue of the shooting area plays a role as the “bridge” or “carrier” to share and diffuse the over heat produced by micro pulsed laser beam so as to avoid skin burnt. During the treatment , biochemical reactions of optical-thermal can accelerate collagen reproduction and skin recovery, after exfoliation of the tiny scar, fresh and smooth skin can be regenerated

Competitive Advantage:
1. Professional designing for hospital, clinic and high qualified beauty salon;
2. Intelligent laser control system ensures a accurate  treatment;
3. CPU imported from America can work stably and has excellent performance.
4. American RF laser driver ensure more stable quality and longer lifetime;
5 .Wide range application, effective treatment;
6 .Easy and fast treatment, no down time
7. CE approval and ISO9001.
