0.19g / kg Bronze Coated Bead Wire Wrapping Uniform Coating 200mm/3m 1700Mpa 2.3mm

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 0 Set / Sets per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Shengda		Place of Origin	China
Model Number	ISO9001

Product Description

Delivery Time:With 20 days after confirmed purchase order

0.19g / kg Bronze Coated Bead Wire Wrapping Uniform Coating 200mm/3m 1700Mpa 2.3mm

Description:

Bead wire for tire rim is widely applied to the manufacturing of various tires rims for automobiles, motorcycles, planes as well as other vehicles.It’s the pivotal material of tire, which can strengthen the tire and is considered an important raw material for the tyre manufacturing business.

Bead wire, its cross section is circular, wire attached to the surface of plating layer, the lap steel carbon content for the 0.80%-0.85%, when the bead wire diameter is 1.50mm, the diameter of the bead wire breaking force is greater than or equal to 3700N, the elongation in4%-7%, flexor strength ratio in 90% - 97% between. Using the improved lap steel strength and fatigue strength, the total strength of the same tire bead wire, can reduce the dosage, the weight of the tire is reduced, reduce the rolling resistance of tire, save energy, and reduce the tire production cost; has high flexion strength ratio, can reduce wire the creep, prolong the life of tires.

Specifications:

Description	BEAD WIRE	Reference	GB/T14450- 2008	Diameter	Φ2.3mm
Item	Standard	Result
Diameter(mm)	2.3±0.02	2.29-2.30
Tensile strength (Mpa)	≥1500	1700-1740
Elongation at break (%)	≥5	5.5-6.5
Torsion(360°/100d)	≥20	28-31
Bronze coated(g/kg)	0.10-0.30	0.19-0.24
Straightness(mm/3m)	≤600	200-500
Surface Quality	Coating Smooth and uniform	conform
