2160N Break Force 0.89mm Dia. Uniform 8.5% Break Tyre Bead Wire For Vehicles, Automobiles
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
1740Mpa Tensile Strength 2.4mm Dia. Annealed Steel Wire Bead Wire For Motorcycles
-
6.0% Break Elongation 1.65mm Dia. Bead Stringing Wire for Planes 2150Mpa Breaking Force
-
Tyre Bead Wire Wrapping With 1242N / 50mm Adhesion And 0.89mm Diameter For Auto
-
450 Straighetness 2156Mpa Tensile Tyre Bead Wire for Automobiles 948N / 50mm 0.78mm
-
Uniform Coating 0.7% Sn Tyre Bead Wire For Vehicles With 2160N Break Force 0.89mm Dia
-
180mm/3m Straightness Tyre Bead Wire Wrapping With 1242N / 50mm Adhesion And 0.89mmHT Dia.
Product Details
| Brand Name | Shengda | Place of Origin | China | |
| Model Number | ISO9001 |
Product Description
2160N Break Force 0.89mm Dia. Uniform 8.5% Break Tyre Bead Wire For Vehicles, Automobiles
Specifications:
|
Description |
BEAD WIRE |
Reference |
GB/T14450- 2008 |
Diameter |
Φ0.89mm |
|
Item |
Standard |
Result |
|||
|
Diameter(mm) |
0.89±0.02 |
0.87-0.91 |
|||
|
Break force (N) |
≥1950 |
1990-2160 |
|||
|
Yield rate (%) |
93.0-96.0 |
93.3-94.9 |
|||
|
Elongation at break(%) |
≥5.0 |
7.0-8.5 |
|||
|
Torsion(360°/200d) |
≥50 |
59-75 |
|||
|
Residual torsion (° /9m) |
≯360 |
90-120 |
|||
|
Bronze coated(g/kg) |
0.35-0.65 |
0.40-0.51 |
|||
|
Sn (%) |
0.5-3.0 |
0.7-1.5 |
|||
|
Straightness (mm/3m) |
≤500 |
180-460 |
|||
|
Adhesion (N/50mm) |
≥1200 |
1242 |
|||
|
Surface Quality |
Coating Smooth and uniform |
conform |
|||
|
Assay of chemical contents |
|||||
|
C |
Mn |
Si |
P |
S |
|
|
0.70-0.72 |
0.50-0.60 |
0.17-0.26 |
0.006-0.016 |
0.005-0.018 |
Description:
Bead wire for tire rim is widely applied to the manufacturing of various tires rims for automobiles, motorcycles, planes as well as other vehicles.It’s the pivotal material of tire, which can strengthen the tire and is considered an important raw material for the tyre manufacturing business.
Bead wire, its cross section is circular, wire attached to the surface of plating layer, the lap steel carbon content for the 0.80%-0.85%, when the bead wire diameter is 1.50mm, the diameter of the bead wire breaking force is greater than or equal to 3700N, the elongation in4%-7%, flexor strength ratio in 90% - 97% between. Using the improved lap steel strength and fatigue strength, the total strength of the same tire bead wire, can reduce the dosage, the weight of the tire is reduced, reduce the rolling resistance of tire, save energy, and reduce the tire production cost; has high flexion strength ratio, can reduce wire the creep, prolong the life of tires.
