Auto Steel Floor Decking Roll Forming Machine For Construction Machinery

Name

floor deck roll forming machine

Use

road

Color

any

Certification

ISO9001:2008

Step of roller

26

Line speed

10M/M

Thickness of middle plate

20

Step of roller

26

Diameter of shaft

90mm

Power of main motor

11kw*2

Motor power of hydraulic station

4kw

Line speed

10m/min

Accuracy of cutting

2mm

Razor blades material

 Cr12, quenching 58-62 °.

Size of the machine

12m (length)*1.5m (width) *1.5m (height)

plc

DELTA

Frequency converter

DELTA

After-sales service provide

 Engineers available to service machinery overseas

Material of frame

360 I beam

Material of shaft

(high grade) 45# Steel,quenching and

Tempering treatment

Material of roller

45# steel

Treatment of roller

Hard chromize coated

Drive type of roll forming machine

Drive by chain

chain

38.1mm(high grade)

Bearing

6210(high grade)

Reducer

9# cycloid reducer(high grade)

voltage

380v/50hz/3 phase

Oil pump of hydraulic station

Gear oil pump(high grade)

Hydraulic cutting

Cutting controlled by PLC

Effective width

910mm

Feeding width

1200mm

Thickness of formed steel

0.5-1.0mm
