Automated Curving Machine , Roof Sheet Arch Plate Roll Forming Machine
Quick Detail:
|
Name |
curving machine |
Application |
Roof |
|
Warranty |
1 year |
Feature |
1.High quality |
|
Color |
Any |
Certificate |
ISO9001:2000 |
Description:
|
Condition |
New |
|
Type |
curving machine |
|
Tile Type |
Colored Steel |
|
Use |
Roof |
|
Power(W) |
1.5KW |
|
Voltage |
380V |
|
Dimension(L*W*H) |
1.3M*0.8M*1.4M |
|
Certification |
ISO |
|
Warranty |
1year |
|
After-sales Service Provided |
Engineers available to service machinery overseas |
|
Color |
any |
|
Material of frame |
(high grade)300mm H shape steel welding |
|
Thickness of middle plate |
25mm |
|
Shaft |
5 |
|
Diameter of shaft |
74mm |
|
Voltage |
380v |
|
Certificate |
ISO9001:2008 |
|
Warranty |
1 year |
parameters of roll forming machine
(1). Material of frame : (high grade) 300mm H shape steel welding
(2).Thickness of middle plate : 25mm
(3). Shaft:5
(4). Diameter of shaft (solid shaft): 74mm
(5). Material of shaft (solid shaft): (high grade) 45# Steel,quenching and tempering treatment
(6). Material of roller: 45# Steel
(7).Treatment of roller : hard chromize coated
(8). Drive type of roll forming machine : drive by hydraulic motor
(9). Bearing : 6210 (high grade)
(10). Power of main motor : 1.5KW
(11). Voltage : 380V/50Hz/3phase
(12). Motor power of hydraulic station : 3kw
(13). Oil pump of hydraulic station : gear oil pump (high grade)
(14). Accuracy of curving : 2mm
(15). Appearance size of main forming machine : 1.3m (length)*0.8m (width) *1.4m (height)
(16). Electrically controlled system : entire machine controlled by PLC
(17). PLC: DELTA(TAIWAN)or Mitsubishi
(18). Controlling desktop : Touch screen (high grade)
(19). Electrical parts : DELIXI or CHINT
Why to choose the Huatong machine ?
1). Material of machine main frame: our is I beam, low price is H beam.
2). Size of machine main frame : our is 360mm, low price is 250-350mm.
3). Thickness of middle plate : our is 14mm, low price is 10-12mm.
4). Type of shaft : our is solid, low price is hollow, they use steel pipe instead of shaft.
5). Diameter of shaft : our is 74mm, low price is 50-60mm.
6). Material of shaft : our is (high grade) 45# Steel,quenching and tempering treatment, low price is ordinary steel and no quenching and tempering treatment.
7). Material of roller : our is (high grade) 45# Steel,quenching and tempering treatment, low price is ordinary steel and no quenching and tempering treatment.
8). Size of roller : our is bigger than low price ma
