High Precision Copper Strip C1100 0.01mm - 2mm , Copper Coils

Name: High Precision Copper Strip C1100 0.01mm - 2mm , Copper Coils
Brand: AS DEMAND
SKU: 149005236
Availability: InStock

Zixu Sheng Ye(kunshan) Metal Technology Co.,ltd

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

AS DEMAND

Place of Origin:

China

Model Number:

1XXX, 3XXX, 5XXX, 7XXX, 8XXX

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Brand Name AS DEMAND

Place of Origin China

Model Number 1XXX, 3XXX, 5XXX, 7XXX, 8XXX

Delivery Time:10-30 days
Certification:ISO9001, ISO14001 and OHSAS 18001

High Precision Electrical Exchanger Transformer Copper Strip With C1100 0.01mm - 2mm

Quick Detail:

Standard Range of Coppers and Copper Alloys Manufactured
coppers	CDA 10200,11000 and 12200 Best Sales Item
Radiator	CDA 14000 series
Lead frame	CDA 19210 new and best
Plain Brassed	CDA 20000 series
Phosphor Bronzes	C51000, C51010, C51110, C52100, and C52400
Nickel Silvers	CDA 73000 to 77000

Description:

Specifications of Transformer Copper Strip:

1. Grade: C1100 , C1020

2. Thickness: 0.005mm- 1.2mm

3. Width: 400mm max

4. Chemical Composition: C1100: Cu >99.90%

C1020: Cu >99.96%

C1220: Cu >99.97%; P 0.015-0.04%

5. Oxygen content: C1100: O < 500PPM

C1020: O < 50PPM

6. Temper: O, 1/4H, 1/2H, H

O: HV<70; 1/4H: HV 65-85; 1/2H: HV 80-100; H: HV >100

7. Electric 20°C Conductivity: C1100/C1020 >97%; C1220 >80%

Item	nominal thickness
Double shiny	Single (double) matte	Super matte
8µm	9µm	12µm	15µm	20µm	10µm	12µm	10µm	12µm
Area Weight (g/m2)	70~75	85~90	100~105	128~133	175~181	95~100	105~110	95~100	105~110
Tensile Strength (kg/mm2)	Normal temperature	≥30.0	≥30.0	≥30.0	≥30.0	≥30.0	≥25.0	≥25.0	≥25.0	≥25.0
Elongation (%)	Normal temperature	≥5.0	≥5.0	≥5.0	≥6.0	≥8.0	≥2.5	≥2.5	≥3.0	≥3.0
Roughness Rz(µm)	≤3.0	negotiable
Thickness (µm)	(-0;+3)	negotiable
Oxidation resistance (160°C/10min)	No oxidation and discoloration
