Three Dimensional Image LCD HMI / Human Machine Interface For Frequency Converter

The Powtech inverter PT-43CT man-machine interface , also known as Stephen real-time online monitoring system, is a visual industrial controllers . 4.3 inch TFT LCD color display with three-dimensional images, animations , images display.

The Powtech inverter PT-43CT man-machine interface using 4 -wire analog resistive touch screen and 32-bit RISC 200MHz clocked CPU, human-computer interaction is very convenient.

The Powtech inverter PT-43CT interface, built-in RS232, RS422, RS485 serial communication port , can be easily connected with a variety of devices . Power : HMI power supply is DC24V or DC5V, 0 PIN: +24 VD or 5V, 1 PIN: 0V. Serial : HMI has an RS232, RS422 and RS485 communication port and a composite way RS232 connection download port .

The Powtech inverter PT-43CT man-machine interface , support for multi-point communication PLC connection , you can connect up to 31 units of the same model PLC. By Download port configuration can be edited under the project file transmitted by the PC HMI, through PIN 2 ~ 9 interface can establish communication with PLC , HMI devices can automatically detect RS232, RS422 or RS485 connection. Note : Use a PC to download the HMI when the project is through the RS232 serial communication , and some PC serial port does not support high-speed communication rate ( eg 115200bps), so as long as the baud rate of the project will be sent down on it.

PT Series HMI Human Machine Interface for controlling industrial processes are visualized . It provides engineers with an easy to use development environment and powerful features , configuration software engineers to quickly build, test and deploy connected . The Powtech inverter real-time online monitoring system is made from the \" System Configuration \" and \" real-time operating system,\" two parts. HMI Func Design Configuration System configuration environment is very similar to VB, C + + BUILDER other visualization advanced programming software, especially important is the introduction of variable configuration software , controls , events, concepts of functional operation , making this software group state of the interface is simple and clear, but it can edit a complex powerful features, this software to learn, approachable , industrial and technical personnel just half a day will be able to skillfully use the software engineering application , greatly shorten your project design development cycle.
