Help CenterNeedle Roller Bearing Without Inner Ring RNA NK Series Shaft Diameter 5mm NK06/10
Related Products
-
Single RowNeedle Roller Bearing With Inner Ring NA NKI NKIS Series NKI 15/16NegotiableMOQ: 1 Set -
Seal Ring Needle Roller Bearing Without Inner Ring RNA 4900RS , RNA4900-2RSNegotiableMOQ: 1 Set
-
High Performance Seal Ring Needle Roller Bearing With Inner Ring , C0 C3 C4NegotiableMOQ: 1 Metric Ton
-
P0 / P5 Seal Ring Needle Roller Bearing for Automobile / Rolling MillNegotiableMOQ: 1
-
Single Row Gcr15 Needle Roller of Chrome Steel / Carbon Steel , C2 C3NegotiableMOQ: 1 Set
Certification:Certification: ISO9001、 OEM
Quick Detail:
Needle Roller Bearing without inner ring RNA NK series NK06/10
Type: Roller Bearing without inner ring
Precision Rating: P0, P6,P5,P4,P2
Material: GCr15,GCr15SiMn, G20Cr2Ni4A
Clearance: C0 C2 C3 C4 C5 as your required
Bearing steel liner: GCr15/100Cr6/SUJ2
Virbration Level: Z1, Z2, Z3, Z4
Noise rank: Z1,Z2,Z3,Z4
Bore Size: 5 - 160 mm
Outside Diameter: 10 - 190 mm
Place of Origin: China (Mainland)
OEM: Accept
Certificate: ISO9001:2008
---------------------------------------------------------------------------------
Description:
|
|
Bearing Designation |
|
BoundaryDimensions |
BasicLoadRating |
Limiting Speed |
||
|
|
|
d |
D |
C |
|
|
Oil |
|
mm |
g |
mm |
N |
rpm |
|
6 |
NK06/10 |
6 |
12 |
10 |
2600 |
2200 |
37000 |
||
|
NK06/10TN |
6 |
12 |
10 |
2600 |
2200 |
37000 |
|||
|
NK06/12TN |
5.7 |
6 |
12 |
12 |
3350 |
3150 |
37000 |
||
|
RNA6X13X8TN |
6 |
13 |
8 |
Needle Roller Bearing without inner ring RNA NK series
Such bearings without inner ring, suitable for installation dimensions restricted radial supporting structure, and bearing directly as a journal to match rolling surface. As a raceway axis, we must quench the hardware and make grinding, and only be processed to the appropriate size and shape accuracy, the full set of needle roller bearingscan be a higher life expectancy and operation of precision. At the same time, because no inner ring, the diameter of shaft can also be appropriate to increase, thereby also increased rigidity.
Needle roller bearings without inner ring can be widelyused in a wide variety of applications, for example as indexing elements, back-stopping clutches or overrunning clutches. The drawn cup roller clutch fulfils the overrunning or holding function as appropriate.
Applications:
l Road Rollers
l Industrial Gearboxes
l Electric Motors
l Automotive Transmissions
l Pumps
l Compressors
l Industrial Fans
l Windmills
l Unbalanced Exciters
l Screw Compressor Applications such as Air Conditioning Systems
Specifications:
1. High rigidity and long life
2. Large load capacity
3 .Good wea
