Silver Gray Iron 1FX + 2 / 3 / 4Port Surveillance Cameras Power Over Ethernet Fiber Switch

Delivery Time:1 Weeks
Certification:CE

Silver Gray Iron 1FX + 2 / 3 / 4Port Surveillance Cameras Power Over Ethernet Fiber Switch

Features:

Desktop PoE(PSE) Ethernet switch. Support 1-port 100Base-FX fiber port. Support transmission by single fiber and dual fibers. Support 4-port 10/ 100Base-TX MDI/MDIX RJ45 ports with PoE(PSE) output. Compliant with IEEE 802.3af specification. Each TP port can output 15.4Watt maximum DC power(48V typical).

Applications:

Supply power to Power Over Ethernet Powered Devices. Wireless LAN Access Points and Bridges. Wireless WiFi Amplifiers and Amplified Antennas. VoIP (Voice over Internet Protocol) Telephones. IP Surveillance Cameras. Bluetooth Access Points.

Technical Specifications:

Standard:

IEEE802.3, IEEE802.3u , IEEE802.3x IEEE 802.3af

Interface Ports:

1-port 100Base-FX fiber port. 4-port 10/ 100Base-TX MDI/MDIX RJ45 ports with PoE(PSE) output up to 15.4Watts per port. PoE power is delivered to the twist-pair through pin 4/5(V+) and 7/8(V-). Power input: DC44-57V ( 1.5A minimum, 48V typical, from external AC/DC adaptor)

LED Indictors:

Power on Indictor : x 1. System state Indicator: x 1 Link/Active: x 5 (FX: x 1, TP: x 4). PoE output state: x 4 .

Environmental Conditions:

Operating temperature : 0 ℃ ~ 40 ℃ Cooling: free air convection Storage Temperature: -20 ℃ ~ 85 ℃ Relative Humidity: 5%~90% non-condensing

Mechanical Specifications:

Case Material: Iron Case Color: silver gray Net Weight: 420g approx. / unit Dimensions: 158mm * 95mm * 27mm
