Stainless Steel Personnel Air Shower Portable Cleanroom With 1.2mm Thickness

Stainless Steel Personnel Air Shower Portable Cleanroom with 1.2mm Thickness

Quick Detail:

1.Name: Customized Stainless Steel Air Shower

2. Brand Name: YIJING

3. Material: All full set Stainless Steel SUS304

4. Feature: Automatic Control

5. Outside dimension: Can be customized

6. Certificates: CE,ISO

Description:

Applicable Number of People: Several persons

Materials: All Full Set Stainless Steel SUS304

Thickness:1.2mm

Number of Nozzle: Based on the customized dimension(Two Sides) Stainless Steel 304

Mouth Diameter of Nozzle:Φ30mm

Speed of Air Flow at the Nozzle:>25m/s

Dimension of High Efficiency Air Filter (mm):600×600×120

Dimension of Air Shower Area (mm): Customized

Outside Dimension (mm): Customized

Lock: Electronic Interlock.

How to use Air Shower?

First, the user enter into the work area, open the door, while the door is auto closed after enter in to the air shower, Auto Showering start, then power off after shower, then the user exit the door enter to clean area. Lastly, the door is auto closed.

Applications:

1. As the filtration equipment through the action of high strength air flow, the single person air shower room is often used in conjunction with clean room. It can remove the impurity such as dust on the working staff before they go into the clean room. Each side of our product has six nozzles with a wide distribution range. With the mouth diameter of 30mm, the nozzle can spray out the air quickly and the air shower area can be up to 800×900×1960mm. The air shower time can be adjusted in the range of 0 to 99s. Thus, the air shower effect can be assured to be the best level, which guarantees the cleanliness of the clean room completely.


2.The double person air shower room is assembled with foam insulation color siding and aluminum component. It is equipped with centrifugal fan and the primary and high efficiency air filters. The product has the features of elegant appearance, compact structure, easy maintenance and simple operation. Meanwhile, we can produce the people and cargo air shower room with the electronic interlocking and infrared sensing device according to customers\' needs.

Specifications
