Toshiba Universal Replacement Laptop Power Adapter Dual USB 5V 1A , US Plug
- T/T L/C D/P D/A
- 7 days
You May Like
-
Desktop 90W Universal Laptop Charger , AC Current To DC Current
-
Asus Universal Laptop Power Adapter RoHS FCC Part 15B With LED Luminous Ring
-
Acer EU Universal Laptop Power Adapter Over Voltage , 50Hz / 60Hz
-
Automatic Universal Laptop Power Adapter Blue LCD Voltage Display
-
2 in 1 notebook power supply , 100W led indicator ,usb used for car
-
DC19V Universal Laptop Power Adapter EMC LVD Approved , Sony
Product Details
Brand Name | RAYTOP | Place of Origin | China | |
Model Number | ET1600400C |
Product Description
Certification:CE, RoHS, FCC
Toshiba Universal Replacement Laptop Power Adapter Dual USB 5V 1A , US Plug
Quick Detail:
Universal laptop adapter 90W, manual output voltage DC 12/15/16/18/19/20/24V, with 2 USB port, each interface output 5V, 1A. The adapter can charge small electronic devices simultaneously when it charge laptops.
Specs:
Input: AC100-240V, 1.8A max.
Output: DC12/15/16/18/20/24V, 3.75A
Power Cord:
AC Cable: 2x0.75mm2, or 3x0.75mm2 length: 1.2M
DC Cable: 18AWG, Copper, length: 1.2M
AC Plug: EU, UK, US, SAA, CCC
Features:
-Worldwide input voltage 100~240Vac;
-High efficiency, up to 82%;
-Protection: Short circuit protection, over voltage protection, over current protection.
-8 different output connectors for top brands laptops.
-MTBF: 50,000 hours.
Approval: CE, RoHS, FCC
Warranty: 2 years
Contents: 1 Adapter + 1AC Cable+1DC Cable +8 Connectors
Description:
This is an universal laptop AC Adapter come with unique design and 8 exchangeable tips, have great compatibility with most top brand notebooks, such as Acer, Asus, Toshiba, Sony, Delta, HP/Compaq, Lenovo, IBM,Gateway, Liteon etc. The users can adjust the slider on the side of the adapter to get different output voltage 12/15/16/18/19/20/24V. The adapter has compact design and high efficiency, very easy to carry and can charge your laptops quickly on going.
Note: please select correct output voltage before connecting the adapter with your laptops.
Applications:
External power supply, used to charge most top brand laptops/notebooks, such as Acer, Asus, Toshiba, Sony, Delta, HP/Compaq, Lenovo, IBM,Gateway, Liteon etc. It can make the laptops continue working even the battery exhausted.
Specifications:
Input |
Rated Input Voltage |
AC100~240V |
Input Voltage Range |
AC 90~264V |
|
Rated Frequency |
50/60 Hz |
|
Input Frequency Range |
47~63 Hz |
|
Input AC Current |
1.8A |
|
Inrush Current |
30A |
|
Output |
Rated Output Voltage |
DC 12~24V |
Output Voltage |
DC12/15/16/18(18.5)/19(19.5)/20(21)/24V |
|
Rated Output Current |
3.75A |
|
Rated Power |
90W |
|
Ripple and Noise |
120mV p-p |
|
Standby Power Consumption |
0.5W |
|
Turn-on |
5s |
|
Hold-up |
20s |
|
Over Voltage Protection |
Yes |
|
Over Current Protection |
Yes |
|
Short Circuit Protection |
Yes, automatically recover after short circuit removed. |
|
Reliability |
Hi-pot |
3000Vac |
Insulation Resistance |
Input to output at 500Vdc |
|
Leakage Current |
5mA |
|
EMI Standards |
FCC Part 15B Class B |
|
RoHS Compliant |
Yes |
|
MTBF |
50,000 hours |
|
Burn-in |
405 ℃, full load, 4 hours |
|
Dr |
