Home > Products > Universal Laptop Power Adapter > Lenovo 70Watt Universal Laptop Power Adapter , 12V - 24V Charger
Lenovo 70Watt Universal Laptop Power Adapter , 12V - 24V Charger
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
Product Details
Brand Name: | RAYTOP | Place of Origin: | China | Model Number: | ET1800400A |
Product Description
Certification:CE, RoHS, FCC
Lenovo 70Watt Universal Laptop Power Adapter , 12V - 24V Charger
Quick Detail:
Universal laptop adapter 70W, manual output voltage12/15/16/18/19/20/24V DC, external power supply when the laptop battery stop working.
Specs:
Input: AC100-240V, 1.2A max.
Output: DC12/15/16/18/20/24V, 2.0A
Power Cord:
AC Cable: 2x0.75mm2, or 3x0.75mm2 length: 1.2M
DC Cable: 20AWG, Copper, length: 1.2M
AC Plug: EU, UK, US, SAA, CCC
Features:
-Wordwide input voltage 100~240Vac;
-High efficiency, up to 82%;
-Protection: Short circuit protection, over voltage protection, over current protection.
-8 different output connectors for top brands laptops.
-MTBF: 50,000 hours.
Approval: CE, RoHS, FCC
Warranty: 2 years
Contents: 1 Adapter + 1AC Cable+1DC Cable +8 Connectors
Description:
This is an universal laptop AC Adapter come with unique design and 8 exchangeable tips, have great compatibility with most top brand notebooks, such as Acer, Asus, Toshiba, Sony, Delta, HP/Compaq, Lenovo etc. The users can adjust the slider on the side of the adapter to get different output voltage 12/15/16/18/19/20/24V. The adapter has compact design and high efficiency, very easy to carry and can charge your laptops quickly on going.
Note: please select correct output voltage before connecting the adapter with your laptops.
Applications:
used for most top brand laptops or notebooks as external power supply, easy to charge your laptops during travel.
Specifications:
Input |
Rated Input Voltage |
AC100~240V |
Input Voltage Range |
AC 90~264V |
|
Rated Frequency |
50/60 Hz |
|
Input Frequency Range |
47~63 Hz |
|
Input AC Current |
1.2A |
|
Inrush Current |
30A |
|
Output |
Rated Output Voltage |
DC 12~24V |
Output Voltage |
DC12/15/16/18(18.5)/19(19.5)/20(21)/24V |
|
Rated Output Current |
2.0A |
|
Rated Power |
70W |
|
Ripple and Noise |
120mV p-p |
|
Standby Power Consumption |
0.5W |
|
Turn-on |
5s |
|
Hold-up |
20s |
|
Over Voltage Protection |
Yes |
|
Over Current Protection |
Yes |
|
Short Circuit Protection |
Yes, automatically recover after short circuit removed. |
|
Reliability |
Hi-pot |
3000Vac |
Insulation Resistance |
Input to output at 500Vdc |
|
Leakage Current |
5mA |
|
EMI Standards |
FCC Part 15B Class B |
|
RoHS Compliant |
Yes |
|
MTBF |
50,000 hours |
|
Burn-in |
405 ℃, full load, 4 hours |
|
Drop Test |
6 direction, each one time from height 1.0M |
|
Environmental |
Operating Temperatur |
