VFD Rubber Wheel Pipe Turning Rolls with Single Motor / 380V Welding Turning Rolls
Quick Details:
Type:Welding rotator/Welding turning rolls/Pipe welding rotator
Brand:Sunny
Condition:100% brand new
Model number:HGZ/HGK
Place of origin:Wuxi China(Mainland)
Usage:Welding
Voltage:110V-600V
Color:Yellow/Blue/Grey
Dimensions and weight:According to the model
Kindly Noted:
1. Model from 5T-150T, others model please confirmed with us.
2. One set of welding turning rolls include one drive & one idler, also customer can choose other combinations.
3. Voltage standard is 380V , 50HZ , 3PH. Other voltage please kindly let us know.
4. Control panel is wired control ,or you can choose wireless control.
5. If customers need more special requirements ,we’ll study with our engineer.
6. Color of the machine is according to the customers.
Description:
The rolls frame is classified into adjustable and self-adjustable types. Each set of rolls frame is comprised of a
driving mount and a driven mount. Two worm reducers of the driving wheel is synchronous operation. The
reducer is made up of frequency changing motor, frequency changer and etc., featured with low noise, stable
turning of work pieces. When linear velocity of work piece turning is 6M/hour to 60M/hour, central distance of
adjustable or self-adjustable rolls frame can be adjusted upon customers’ demand. Clamp frame of the
self-adjustable rolls frame can be self-adjusted with corresponding diameter of working pieces to save labor
force and increase working efficiency.
Applications:
Welding Rotator major used in cylinder welding ,such as Marine,Oil&Gas ; Offshore,Petro Chemical ; Plate Heat
Exchanger ; Charged air cooler ; Pressure Vessel ; Boiler ; Pipe system&Steel works etc.
Specifications:
|
Type |
Max loading (kg) |
Vessel diameter(mm) |
Dia. and width of the wheel(mm) |
Roller linear velocity(m/h) 6-60 |
Power of motor(kw) |
|
Rubber rollers |
Metal rollers |
||||
|
HGZ-5 |
5000 |
Φ250-2300 |
Φ250×100 |
2×Φ240×20 |
0.75 |
|
HGZ-10 |
10000 |
Φ320-2800 |
Φ300×120 |
2×Φ290×25 |
1.5 |
|
HGZ-20 |
20000 |
Φ500-3500 |
Φ350×120 |
2×Φ340×30 |
2.2 |
|
HGZ-40 |
40000 |
Φ600-4200 |
Φ400×120 |
2×Φ390×40 |
3 |
|
HGZ-60 |
60000 |
Φ750-4800 |
Φ450×120 |
2×Φ440×50 |
4 |
|
HGZ-80 |
80000 |
Φ850-5000 |
Φ500×120 |
2×Φ490×60 |
4 |
|
HGZ-100 |
100000 |
Φ1000-5500 |
Φ500×120 |
2×Φ490×80 |
|
