10" Water Filter Cartridge Housing For Industrial , Ceramic Filter Cartridge

Delivery Time:Negotiable
Certification:ISO 9000

10\" Water Filter Cartridge Housing For Industrial , Ceramic Filter Cartridge

Quick Detail:

Tri-clamp cartridge filter housings are easier installation and higher operating pressure with our own patent design for closure. It avoids o-ring seal leakage maximum.

Description:

Patent design of closure: Easier installation, higher pressure available

- ASTM SS304 or SS316L stainless steel construction for best chemical compatibility and corrosion resistance.

- Two styles of surface finish (both inside and outside): Mirror-polish or Bead blasted

- All filter housings hydrostatically tested

- Available for many kinds of filter cartridges:

PP melt blown filter cartridge, 222 pleated filter cartridge, 226 pleated filter, DOE pleated filter cartridge, Ceramic filter cartridge, etc;

- Patent design to prevent bypass leakage.

- Multi-choices of seal material to meet different needs:

Silicon rubber, EPDM rubber, Viton rubber;

- 150 PSI (1.0Mpa) pressure available

- Standardised flanges and threads: DIN, BSP, ANSI

- Micron Ratings: 0.1-100micron

- Custom designs available.

Accessories included: pressure gauge, air release valve

Packaging: carton or wooden case

Applications:

Commercial/Residential Drinking Water Cooling Tower Filtration Process Water Reverse Osmosis Pre-Filtration Ground Water Remediation Utility Water Industrial Waste Water Treatment Ground Water Under Direct Influence (GUDI)

Specifications:

Model	No. Of Cartridge	Cartridge Length	Diameter (mm)	Housing Height (mm)	Inlet Height (mm)	Outlet Height (mm)	Inlet& Outlet (inch)
CFH-TCS-0310	3	10 inch	180	500	300	100	2″
CFH-TCS-0320	3	20 inch	180	750	300	100	2″
CFH-TCS-0330	3	30 inch	180	1000	300	100	2″
CFH-TCS-0340	3	40 inch	180	1400	300	100	2″
CFH-TCS-0510	5	10 inch	180	500	300	100	2″
CFH-TCS-0520	5	20 inch	200	750	300	100	2″
CFH-TCS-0530	5	30 inch	200	1000	300	100	2″
CFH-TCS-0540
