High Efficiency Constant Current Led Driver , 34V 1.0A 35W Led Drivers For Lighting
Feature:
. Universal AC Input
. Power Factor Built In , PF > 0.9
. Protections: Overload, Short Circuit
. Screw terminal connection
. 2 Years Warranty
Description:
34V1.0A 35W Constant Current LED Driver PFC Built In
|
Electronic Specifications : |
|
|
Input Voltage Range : |
90~264Vac; 120~370Vdc |
|
Input Frequency : |
50/60Hz |
|
Power Factor : |
> 0.9 |
|
AC Input Current (Max.) : |
0.45A/100Vac |
|
Normal Output Voltage : |
34.0Vdc |
|
Output Current : |
1000mA |
|
Power (Max) : |
35.0W |
|
Efficiency : |
＞80% |
|
Output Short Circuit Protection : |
Can be Shorted without damage and auto recovery. |
|
Environment : |
|
|
Working Temp.: |
0~40℃ |
|
Working Humidity: |
20%~90% RH non-condensing |
|
Storage Temp. & Humidity: |
-20℃~85℃, 10%~95% RH |
|
Reliability : |
|
|
Hi-Pot Testing Voltage : |
I/P to O/P : 3.0 (60Sec.) KVac |
|
Safety Standard : |
EN60335-2-29 |
|
EMI Standard : |
EN55022B |
|
Mechanic : |
|
|
Case Size : |
140 * 38 * 28 mm ( L * W * H) |
Applications:
Widely Used LED Lights
