J54-1000ton Impact Press Machine / Cookware Press With Large Energy

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 0 Set / Sets per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Hongduan		Place of Origin	China
Model Number	J54-1000ton

Product Description

Delivery Time:30-90 word day
Certification:ISO9001;CE

J54-1000ton Impact Press Machine / Cookware Press With Large Energy

Quick Detail:

1. whole stroke brake

2. photoelectricity protection system.

3. saving energy and materials

4. high efficiency

5. simple and stable structure

6. large energy

7. long working life

Description:

J54 series cookware press is an advanced machine to make stainless steel impact-bonding bottom

cookware. It adopts heat-pressure technology to attach a copper or aluminum disc to the bottom of a

stainless steel pan. This machine has following advantages:

1. whole stroke brake

2. photoelectricity protection system.

3. saving energy and materials

4. high efficiency

5. simple and stable structure

6. large energy

7. long working life

Applications:

J54 series cookware press is an advanced machine to make stainless steel impact-bonding bottom

cookware. It adopts heat-pressure technology to attach a copper or aluminum disc to the bottom of

a stainless steel pan.

Specifications:

Main Parameters	unit	J54-630D	J54-1000C	J54-1600C	J54-2500	J54-4000
Nominal Force	kN	6300	10000	16000	25000	40000
Energy	kJ	80	160	280	500	900
Max load (central loading)	kN	10000	16000	25000	40000	63000
Ram stroke	mm	600	700	700	800	800
No. of Stroke	min-1	11	10	10	9	9
Guide rail distance	mm	715	1004	920	1100	1128
Ram dimension	front/back	mm	760	1190	1000	1560	2000
left/right	mm	700	800	900	1060	1100
Table dimension	front/back	mm	920	1200	1250	1560	2200
left/right	mm	820	1000
