API 5L X42 12M Welded Steel Pipes LSAW For Water Low Resistance

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name

TJJX

Place of Origin

China

Delivery Time:12days
Certification:API, CE, ISO

API 5L X42 12M Welded Steel Pipes LSAW For Water Low Resistance

Quick Detail:

Material:ASTM A53, ST52, API 5LX42, 52, 60

Production Technology:LSAW

Product:LSAW welded pipe

Description:

LSAW-Longitudinal Submerged Arc Welded should be for spot welding and welding by one side.It is a straight line and very beautiful and good.

LSAW pipe produce progress:

(1) The machine will make the steel material to J than C, the last is O. So the pipe is round.

(2) Cut the steel material, make it fit for the pipe.

(3) Bend the material, this step is facility for welding.

(4) All the steps finish, will put this pipe into stock.

(5) Test: ultrasonic testing.hydrostatic test.

(6) Welding: Pre-welding,inner welding, outside welding

(7) We will check the material, and confirm the material is good.

Specifications:

Product:LSAW carbon pipe Brand:TJJX Specification: OD:273-1420mm Thickness:6-20mm Length:12m Standard:ASTM A 53 ASTM A210-C API 5L X42, 52,60 Production Technology:LSAW Tolerance:OD:±2-3%mm WT:2-3%mm Length:±20mm	Diameter	Thickness	Diameter	Thickness
273.1mm	6.4/6.75/7.78/9.48/10.58/12.5	508mm	10.58/12.5/13.75/19.1
323.9mm	6.75/7.78/9.48/10.58/12.5/13.75	530mm	10.58/12.5/13.75/19.1
351mm	6.75/7.78/9.48/10.58/12.5/13.75	560mm	10.58/12.5/13.75/19.1
355.6mm	6.75/7.78/9.48/10.58/12.5/13.75	609.6mm	10.58/12.5/13.75/19.1
377mm	6.75/7.78/9.48/10.58/12.5/13.75	630mm	10.58/12.5/13.75/19.1
402mm	6.75/7.78/9.48/10.58/12.5/13.75	720mm	10.58/12.5/13.75/19.1
406.4mm	7.78/9.48/10.58/12.5/13.75/17.8
426mm	7.78/9.48/10.58/12.5/13.75/19.1
450mm	7.78/9.48/10.58/12.5/13.75/19.1
457.2mm	7.78/9.48/10.58/12.5/13.75/19.1
480mm	7.78/9.48/10.58/12.5/13.75/19.1
Spec Description
Chinese	English
OD	WT	OD	WT
219*1420mm	6-20mm	8-52inch	0.24-0.78inch
