Product Details
| Brand Name | TJJX | Place of Origin | China | |
Product Description
Certification:API, CE, ISO
ASTM A53 ST52 Longitudinal Submerged Arc Welding High Pressure
Quick Detail:
Product:LSAW welded pipe
Production Technology:LSAW
Material:ASTM A53, ST52, API 5LX42, 52, 60
Description:
LSAW-Longitudinal Submerged Arc Welded should be for spot welding and welding by one side.It is a straight line and very beautiful and good.
LSAW ADVANTAGE:
High pressure,Little resistance,Under low temperature, Under corrosion,Easy installation and maintenance.
LSAW pipe produce progress:
We will check the material, and confirm the material is good. Cut the steel material, make it fit for the pipe. Bend the material, this step is facility for welding. The machine will make the steel material to J than C, the last is O. So the pipe is round. Welding: Pre-welding,inner welding, outside welding Test: ultrasonic testing.hydrostatic test. All the steps finish, will put this pipe into stock.Specifications:
|
Product:LSAW carbon pipe Brand:TJJX Specification: OD:273-1420mm Thickness:6-20mm Length:12m Standard:ASTM A 53 ASTM A210-C API 5L X42, 52,60 Production Technology:LSAW Tolerance:OD:±2-3%mm WT:2-3%mm Length:±20mm |
Diameter |
Thickness |
Diameter |
Thickness |
|
273.1mm |
6.4/6.75/7.78/9.48/10.58/12.5 |
508mm |
10.58/12.5/13.75/19.1 |
|
|
323.9mm |
6.75/7.78/9.48/10.58/12.5/13.75 |
530mm |
10.58/12.5/13.75/19.1 |
|
|
351mm |
6.75/7.78/9.48/10.58/12.5/13.75 |
560mm |
10.58/12.5/13.75/19.1 |
|
|
355.6mm |
6.75/7.78/9.48/10.58/12.5/13.75 |
609.6mm |
10.58/12.5/13.75/19.1 |
|
|
377mm |
6.75/7.78/9.48/10.58/12.5/13.75 |
630mm |
10.58/12.5/13.75/19.1 |
|
|
402mm |
6.75/7.78/9.48/10.58/12.5/13.75 |
720mm |
10.58/12.5/13.75/19.1 |
|
|
406.4mm |
7.78/9.48/10.58/12.5/13.75/17.8 |
|||
|
426mm |
7.78/9.48/10.58/12.5/13.75/19.1 |
|||
|
450mm |
7.78/9.48/10.58/12.5/13.75/19.1 |
|||
|
457.2mm |
7.78/9.48/10.58/12.5/13.75/19.1 |
|||
|
480mm |
7.78/9.48/10.58/12.5/13.75/19.1 |
|||
|
Spec Description |
||||
|
Chinese |
English |
|||
|
OD |
WT |
OD |
WT |
|
|
219*1420mm |
6-20mm |
8-52inch |
