50HZ AC 220V Sectional Garage Door Opener Drive With Remoto Control

Delivery Time:Garage door opener for automatic operation shipped within 10-15 days
Certification:CE
50HZ AC 220V Sectional Garage Door Opener Drive With Remoto Control

Quick Detail:

1. Garage door drive

2. Secure rolling code transmitters

3. Automatic force mapping

4. Wireless wall console

5. Maintenance monitor

6. Soft start and stop

7. Delivery time: according to your quantity of motors

8. When opening or closing, the light comes on automatically and remains on for three minutes.

Description:

1. Max liftingt: 8 m²

2. Max lifting height: 3 M

3. Equipped track length:3.3M (For door 2.4M)

4. Standard equipment: 2 transmitters

5. Rolling code / Digital limit switch

6.Our big markets: main customers are from Europe ,the USA,Canada,Russia,Mexico ,middle east ,etc.

7. Low noise & smooth operate Remote

8. Optional auto closing function, allows for automatic closing of door after three minutes, preceded by 15 second flashing warning light.

9. Easy programming Limit Travel and Lift Force. Programmed data remain stored,even after power failure.

10. Input power: AC 220V, 50HZ/AC110V, 60HZ

11. Motor power: DC 24V

12. Radio frenquency: 433.92MHZ

13. Output torque: 6N.M, 8N.M 10N.M, 12N.M, 15N.M

14. Components included: 2 transmitters, guide and other mounting brackets

15. Options: Wall switch, photocell, transmitters

Applications:

1. Guide the door to up and down with the help of torsion spring.

2. Max square metre:10square metre

3. sectional garage door opener,garage door opener, garage door operator, electric sectional door motors

Specifications:

Item No	MO.SGD1800
Name	Garage door motor/opener
Usage	Garage door energy
Power Input	220V AC ±10% 50-60HZ
Reception Frequency	433.92MHZ
Motor	24V DC
Decoding	Rolling Code
Working Temperature	>-20℃, <+50℃
Transmitter Power	27A 12V Battery
Courtesy Light Time	3 minutes
Open and close force	600N, 800N, 1000N, 1200N
Min Order Quantity	100 Sets
Supply Ability:	3000 Sets

Opotional Accessories:

Other optional accessories for motor, such as wireless pin code lock, photocell, and wireless wall switch.

Competitive Advantage:

1.  Low MOQ: One set is available for checking our quality first conveniently.

2.  Good Quality: Your client satisfied on our quality. You can get good reputation from your market and obtain more orders.

3.  Good Service: Our professional service before and after sale.

4.  The reasonable price

5.  Fast & Cheap Delivery: We have big discount from forwarder (Long Contract).

6.  OEM is welcome.

Package for Motor:

About Master Well:

We have been in garage door for years, including the panel, accessories and motor, such as torsion spring, top bracket, bottom bracket, central bearing bracket, roller ( nylon, plastic or steel roller), lift handle, cable drum, tube shaft, flag bracket and so on.

Also we provide the service of garage door installation, hope we can be helpful in your business.

Contact us freely, we are not only the supplier, but also your good friends!
