Auto Electronic Gas Igniter For CNC Flame Cutting Machine AC 24V / 220V

Name: Auto Electronic Gas Igniter For CNC Flame Cutting Machine AC 24V / 220V
Brand: Longteng
Price: Negotiable

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Supply Ability 0 Piece / Pieces per Month
Payment Terms:T/T L/C D/P D/A
Delivery Detail:7 days

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:

Longteng

Place of Origin:

China

Model Number:

LT-DH

Product Description

Delivery Time:7-15 days after the payment
Certification:CE,ISO

Auto Electronic Gas Igniter For CNC Flame Cutting Machine AC 24V / 220V

1) Quick Detail:

1. Auto Igniter

2. Use for ignition and spark beside the flame cutting torch

3. Equipped with solenoid valve and high-voltage unit

2) Description:

1. The Automatic Igniter is equipped with solenoid valve and high-voltage unit, which is installed on the cutting torch to adjust the distance between the cutting nozzle and ignition source.

2. When power is on, with the help of the solenoid valve the high-voltage unit will bring about fire source, which will meet with the fire hole of the cutting nozzle to realize ignition.

3. By using the ignition device, which makes it easier to work, and can improve efficiency and reduce the inefficient combustion time of the cutting nozzle.

4. The small holder has two kinds 30mm and 32mm, which according to the O.D. of the cutting torch for the machine use.

5. The high voltage unit is the transformer, which could transform the low voltage into the high voltage, then get the spark and ignition function, when the sparkle meet the fuel gas, which will get flame to ignite the cutting tip for cutting.

1> Standard Configuration

Holder: 1

High-voltage unit:1

High-voltage cable:1 (1.5 M)

Flashback arrestor: 1

Gas valve: 1

Solenoid valve:1

Gas inlet assembly:1

Copper connecting terminal:1

a). AC 24V power supply, with safe and reliable aviation connector

b). High pressure electronic igniter is used

c). Special mini-valve control is designed

d). Acetylene back flash arrester ensures no back flash impact the main gas supply pipe

e). 1/4\"-LH or 6mm connector is adopted

3) Applications:

Use for CNC Flame Gantry Cutting Machine and the CNC Portable Cutting machine.

Beside the cutting torch, it achieves the convenience with the automation design, which could avoid using the lighter for igniting the oxy-fuel cutting torch.

4) Specifications:

Model Number	LT-DH
Brand Name	Longteng, OEM
Place of Origin	Wuxi, China (Mainland)
Certification	CE,ISO
Loading Port	FOB Shanghai
Payment Terms	T/T, L/C, Western Union
Supply Ability	2000 pieces/month
Current and Voltage	AC 24V/220V,DC 24V
Cable length	1.5 M/2M/1.8M
control mode	CNC
plasma source	Flame
Driving form	Electric

5) Competitive Advantage:

1> Product Advantage:

1. Using high frequency discharge ignition circuit and arc temperature is higher, easy to ignite the gas.

2. Auto Igniter is durable because of the special craft processing .

3. The gas solenoid valve and discharge are synchronously controlled, which can reduce waste.

4. 100% inspection on critical dimensions with high accuracy 0.01-0.005mm

2> Factory Advantage:

1. Professional manufacturer for CNC cutting machine accessories

2. More than 16 years experience

3. Factory direct price and on time delivery

4. Secure ordering and worldwide delivery

5. Sample available

6. Small quantity acceptable

7. OEM workable

Electronic Gas Igniter Component

Electronic Gas Igniter Application

ignition auto

auto ignition

ignition device for cnc cutting machine
