Adjustable 5200mAH Smart Li-Ion Heated Clothing Battery With Protection Circuit

Lixiang Energy Co., Ltd
Adjustable 5200mAH Smart Li-Ion Heated Clothing Battery With Protection Circuit thumbnail-1
Adjustable 5200mAH Smart Li-Ion Heated Clothing Battery With Protection Circuit photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
BAK, SAMSUNG or SANYO CELL Optional
Place of Origin:
China
Model Number:
LX-DRF05H
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name BAK, SAMSUNG or SANYO CELL Optional
Place of Origin China
Model Number LX-DRF05H
Delivery Time:3~15 days
Certification:CE, FCC, RoHs

Adjustable 5200mAH Smart Li-Ion Heated Clothing Battery With Protection Circuit

Parameters

Model No.

LX-DRF02H

Nominal Voltage

7.4v

Working Voltage

6V-8.4V

Nominal Capacity

5200mAh

Charge Cut-off Voltage

8.4v

Charge Current

200mA—1200mA

Standby Current

≤100μA

Max. Output Power

20W MAX

Operating Efficiency

≥99%

Loading Resistance

5Ω-200Ω

Charge Method

CC/CV Constant Current/Constant

Charge Temperature

0℃—40℃

Discharge Temperature

-20℃～ +60℃

Charge Duration

4-5hrs(Standard)

Cycle Life Time

Above 500 cycles

Internal Impedance

PCB Internal Impedance<80mΩ;

Battery Internal Impedance <180mΩ

LED Display

4-heat settings, capacity indication

Output Terminal

DC3.5*1.35*7mm

Usage

Heated clothing, heated seat cushions, etc.

Battery Size

92*72*23mm

Weight

230g

Color

White, black, red, pink, blue, brown, etc.

Certificates

CE, FCC, ROHS

Lead Time for Sample

3~7 days

Lead Time for Bulk Order

7~15 days

Features:

1. BAK, SAMSUNG or SANYO CELL Optional

2. Smart Power Management

3. LED Display

4. Four adjustable pulse outputs

5. Protection circuit inside

6. Different colors are optional

7. CE, FCC, RoHs Compliant

8. One Year Warranty

Operation:

Power Indication:

①No Load, press ON/SETUP button to power on, LED in RED color, 90%<= power<=100%

②No Load, press ON/SETUP button to power on, LED in ORANGE color, 30%<= power<=90%

③No Load, press ON/SETUP button to power on, LED in GREEN color, power<=30%

Remaining Capacity

LED#1

90~100%

●

30%～90%

●

0%～30%

●

Output Indication:

①Press ON/SETUP button, LED in RED color, the output power=98%

②Press ON/SETUP button, LED in ORANGE color, the output power>=75%

③Press ON/SETUP button, LED in GREEN color, the output power>=50%

④Press ON/SETUP button, LED flash, the output power>=25%

⑤Press ON/SETUP button, LED is off, the battery power off

Output Power

LED#1

98%

●

75%

●
