7500 Nits P16 Outdoor LED Screen Rental With 1R1G1B Epistar LED Chip
Certification:CE,ROHS
7500 nits P16 Outdoor LED Screen Rental with 1R1G1B Epistar LED Chip
Quick Detail:
1. 256×256 mm LED module;
2. 3,906 dots/sq.m;
3. Static scan;
4. 1R1G1B;
5. All Epistar LED;
6. R9 GB9×12 chip size.
Detail Description:
Big rental LED display, electrifying effect;
Professional design of LED box, not only easy to mount, but also dismantal simply;
Installation guide on the spot brings you more technical solutions.
Application:
Rental LED display screen is installed on public for concert, events, etc in general.
Specifications:
|
Model |
PH16 |
|
LED Composition |
1R1G1B |
|
LED Type |
DIP546 |
|
Resolution |
3,906 dots/sq.m |
|
LED Module Pixel |
W 16 × H 16 |
|
LED Module Size |
W 256 × H 256 mm |
|
Standard Cabinet Size |
W 768 × H 768 mm |
|
Module Quantity in a Cabinet |
W 3 × H 3 PCS |
|
Cabinet Material |
Aluminum waterproof cabinet |
|
Driving Method |
Static scan |
|
Brightness |
≥7500 CD/sq.m |
|
Refresh Rate |
≥1200Hz |
|
Out of Control Dot Rate |
<0.0001 |
|
Earth Leakage Current |
<2mA |
|
MTBF |
>5,000 hours |
|
LED Life Span |
>100,000 hours |
|
Power Supply |
110V/60HZ and 220V/50HZ interchangeable |
|
Humidity |
10%~90% |
|
Control Method |
Synchronous control with PC on |
|
Input Signal |
DVI, COMPOSITE VIDEO, S-VIDEO, HDMI |
P16 Outdoor LED Screen Rental, Outdoor LED Rental Screen, High Brightness Outdoor LED Screen Rental
