BOPP/BOPET Capacitor Film clear
1. BOPP capacitor film have two items, BOPP clear capacitor film and BOPP rough clear capacitor film.
1.)M-PP for metallized -film capacitors applications .
2.)S-PP for foil-film capacitors applications .
The standard thickness range including: 3 ,4,5,6,7,8,9,10,12 microns .
The standard tolerance thickness: 0.2 Um .
The width range including: can slit any width(MM )upon the requirement.
The inner core : 3" (76MM)
The outer core: 150-350 MM .
BOPP Capacitor film included RPP BOPP capacitor film,RRPP BOPP capacitor film, Polypropylene metallized capacitor Film (Zn metallized film,zn/al BOPP capacitor film),capacitor foil film
2. BOPP rough clear capacitor film .
1.)R-PP : one side of rough capacitor film ( power capacitor use).
2.)RR-PP: two sides of rough capacitor film .
The thickness range including: 6,7,8,9,10,12,18 microns .
The width range including: can slit any width (MM) upon the requirement.
The inner core : 3" (76MM),6'(152MM)
The outer core: 150-350 MM .
Features:1) single side corona treated for the Zn or Zn/Al metallized .
2. BOPET capacitor film (Polyester capacitor film) have two items: clear/transparent BOPET capacitor film and silver metallized BOPET capacitor film
1.) BOPET capacitor film were used for film-capacitor (and other electrical insulation material.) which features dielectric strength, dielectric constant and volume resistance, low dielectric loss, good mechanical performance and dimension stability.
BOPET capacitor film also called PET Capacitor film,clear Polyester capacitor film,transparent Polyester capacitor film,
Thickness:3-12UM Width: 500,620,910,980,1010,1300 MM
Net weight per roll about: 50KGS/roll
Inner plastic tube core: 3',6'(76MM ,152MM )
2.) BOPET metalized VM/--Zn/Al capacitor film (Metallized BOPET Capacitor Film,sliver PET Capacitor film). Thickness:3-12UM Width: 500,620,910,980,1010,1300 MM
