Stainless Steel Material J518 SAE Split Flange with Pressing Process
Quick Detail
Description:
The products widely used in petrol, the chemical industry, construction machinery and equipment. Support for the hydraulic piping system.
1Material: cast steel, alloy steel, stainless steel, copper, plastic, ppc
2Process: pressing, forging,casting
3Standard: GB, ANSI, DIN, JIS,
Application:
Construction, engineering machinery ,marine, special vehicles
Competitive Advantage:
Established in 1996,CHANGZHOU HANYUN HYDRAULIC COMPONENTS MGF.CO.LTD.is a manufacturer specialized in hydraulic flange and fittings for a variety of hose, pipe and tube assemblies. The products widely used in petrol, the chemical industry, construction machinery and equipment. Support for the hydraulic piping system.
The manufacturing center covers an area of 12000 square meters. There are 250 high quality staff in our company, two senior engineers, ten technical personnel. We have CNC machining center, CNC lathes, CNC milling machine, CNC bending machine; as well as 200-odd pieces of turning, milling, grinding, EDM, punching machines and other types of testing equipment. The products rank first for the quality in their kind in our country. Professional production, scientific management and good workforce, making our products exported to Europe, the United States market, the quality of products obtained customer satisfaction. Our quality management has been certified to the ISO9001:2000 standard., we have the professional scientific research institutions and the trustworthy sales service system. We are providing all-round top-notch services for a large number of global subscribers.
The goal we are pursuing is Quality First with Superior Service.
| CD61(3000PSl) | ||||||||||||||
| PART NO. |
FLANGE SIZE |
A | B | C | D | E | F | G | H | J | SAE | METRIC | ||
| K | HHCS | K | HHCS | |||||||||||
| HY57-61-8-8-SS | 1/2 | 45.97 | 53.85 | 17.48 | 38.1 | 19.05 | 12.7 | 30.96 | 24.26 | 6.22 | 8.74 | 5/16-18 | 9 | M8x20 |
| HY57-61-12-12-SS | 3/4 | 52.32 | 62.02 | 22.23 | 47.63 | 22.35 | 14.22 | 38.89 | 32.13 | 6.22 | 10.31 | 3/8-16 | 11 | M10x25 |
| HY57-61-16-16-SS | 1 | 58.67 | 69.85 | 26.19 | 52.38 | 23.88 | 15.75 | 45.24 | 38.48 | 7.49 | 10.31 | 3/8-16 | 11 | M10x30 |
| HY57-61-20-20-SS | 1 1/4 | 73.15 | 79.25 | 30.18 | 58.73 | 22.35 | 14.22 | 51.59 | 43.69 | 7.49 | 11.91 | 7/16-14 | 11 | M10x25 |
| HY57-61-24-24-SS | 1 1/2 | 82.55 | 93.73 | 35.71 | 69.85 | 25.4 | 15.75 | 61.11 | 50.8 | 7.49 | 13.4 |
