Precision CNC Gear Cutting Machines For Straight Bevel Gear , Maximum Range 1 - 8mm

Precision CNC Gear Cutting Machines For Straight Bevel Gear , Maximum Range 1 - 8mm

Quick Detail:

Model Y236B Machine is designed for cutting Straight Bevel Gears with the diameter up to 600mm and module to 10mm. It is suitable for the mass production, and for the jobbing and batch productions as well.

Description:

1) The machine employs two standard reciprocating side cutting tools for finishing cut with generating method and roughing cut with in-feed method.
2) It is a semi-automatic machine with easy operation and enough rigidity. The machine accuracy and the service life can be kept for a long-term.
3) The rigid work spindle with a larger taper hole widens the application ranges and the arbor sleeves are available for both Metric and Morse taper arbors.
4) The machine accuracy and the electrical equipment are conformable with the relative National Standard, for the reliable accuracy and safe operation of the machine.

Features of Machine:

1.This machine implements the International Standards therefore its machining accuracy is increased;
2. The rigid and enlarged bore of the work spindle taper hole widens the application range and arbor sleeves are

available for both metric and Morse taper arbors;
3. In accordance with the IEC general requirements, the electrical equipment of the machine is safe and reliable;
With improved lubrication system, the operation of the machine is easy.
Specifications of Machine
Maximum diameter of work 600 mm
Maximum range of module of work 1-8mm
Maximum model capable to be cut 10mm
Maximum pitch cone distance 305mm
Extreme ratio 1:10
