Home > Products > Bead Stringing Wire > 0.27g/kg Bronze Coated 500mm/3m Straightness Uniform Smooth Bead Stringing Wire 1.55mmHT
0.27g/kg Bronze Coated 500mm/3m Straightness Uniform Smooth Bead Stringing Wire 1.55mmHT
- T/T L/C D/P D/A
- 7 days
You May Like
-
Uniform Coating 2100Mpa Tensile Strength Bead Stringing Wire for Motorcycles 1.60mmHT
-
1900Mpa Breaking Force Bead Stringing Wire for Automobiles 6.0% Break Elongation 1.65mm
-
98.3% Cu 87.6% Yield Ratio Bead Stringing Wire for Planes 2150Mpa Breaking Force 1.65mmHT
-
6.0% Break Elongation 0.32g/kg Bronze Coated Bead Wire Wrapping for Vehicles 1.83mm
-
1.7% Sn 87.6% Yield Ratio 2050Mpa Breaking Force Bead Wire Wrapping for Planes 1.83mmHT
-
29 Torsion 5.0 Break Elongation Uniform Coating Bead Wire Wrapping for Motorcycles 2.0mm
Product Details
| Brand Name | Shengda | Place of Origin | China | |
| Model Number | ISO9001 |
Product Description
0.27g/kg Bronze Coated 500mm/3m Straightness Uniform Smooth Bead Stringing Wire 1.55mmHT
Description:
Bead wire for tire rim is widely applied to the manufacturing of various tires rims for automobiles, motorcycles, planes as well as other vehicles.It’s the pivotal material of tire, which can strengthen the tire and is considered an important raw material for the tyre manufacturing business.
Bead wire, its cross section is circular, wire attached to the surface of plating layer, the lap steel carbon content for the 0.80%-0.85%, when the bead wire diameter is 1.50mm, the diameter of the bead wire breaking force is greater than or equal to 3700N, the elongation in4%-7%, flexor strength ratio in 90% - 97% between. Using the improved lap steel strength and fatigue strength, the total strength of the same tire bead wire, can reduce the dosage, the weight of the tire is reduced, reduce the rolling resistance of tire, save energy, and reduce the tire production cost; has high flexion strength ratio, can reduce wire the creep, prolong the life of tires.
Specifications:
|
Description |
BEAD WIRE |
Reference |
GB/T14450- 2008 |
Diameter |
Φ1.55mmHT |
|
Item |
Standard |
Result |
|||
|
Diameter(mm) |
1.55±0.02 |
1.53-1.56 |
|||
|
Tensile strength (Mpa) |
≥2050 |
2040-5060 |
|||
|
Elongation at break (%) |
≥5 |
5.0-6.0 |
|||
|
Torsion(360°/100d) |
≥25 |
29-38 |
|||
|
Bronze coated(g/kg) |
0.15-0.30 |
0.27 |
|||
|
Straightness(mm/3m) |
≤600 |
200-500 |
|||
|
Surface Quality |
Coating Smooth and uniform |
conform |
