Crane Leg Fixing Type Building Tower Crane For Civil Buildings / Wharf

Crane Leg Fixing Type Building Tower For Civil Buildings / Wharf

1. Specification: TCP6512A-10

2. standard section Dimensions:  2,000mmX2,000mmX3,000mm

3. Material: All main chord be made of  Q345B steel

4. Parameter: Maximum hoisting capacity is 10 tons, the longest jib is 65m, maximum independent lifting height is 53m, maximum attached height is 180m.

5. Model : QTZ125

Quick Detail:

TC6512A-10t ower crane (QTZ125)

1. Mast standard section: 1,800mmX1,800mmX2,800mm ,1835mmX1835mmX2500mm,

    Plate standard section: 2,000mmX2,000mmX3,000mm.

2. The longest jib is 65m,  the jib combination decreases progressively 5m each and the minimum jib length is 45m.

3. The maximum hoisting capacity is 10 tons.

4. The maximum lifting capacity at a distance of 65m is 1.2ton.

5. The maximum independent height is 53m and the maximum attached height is 180m.

6. Hoisting mechanism: Adopting a variable frequency motor   37KW .

7. Slew mechanism: Adopting a torque motor   5.5KWX2 .

8. Luffing mechanism: Adopting a variable frequency motor    5.5KW .

9. Tower crane foundation type: Embeded leg fixing type. Stone bolt fixing type

Description:

 Our main products are:

Hammer head tower crane QTZ63(TC5013),QTZ80(TC5610,TC5610A,TC6010TC,TC6010A)QTZ100(TC6013-6,TC6013A-6,TC6013-8,TC6013A-8)QTZ125(TC6015-8,TC6015A-8,TC6512-10,TC6512A-10)QTZ160(TC7013-10,TC7013-12)QTZ250(TC7520-12,TC7520-16)

Flat head tower crane QTZ125(TCP6015-8,TCP6512-10)QTZ160(TCP7013-10,TCP7013-12)

TC6512A-10(QTZ125)The crane is a new developed type. The lifting arm has good feasibility and availability. Lifting mechanism and luffing mechanism adopt variable frequency motor, slewing mechanism adopts torque motor. The maximum hoisting weight is 10T, attached height is 180m, can meet the needs for building of high- rise and super high- rise .  The jib length is 65m, can meet the application for the building with large span. Adopting the plate type standard section which can be exchanged with POTAIN\'s one. The transportation is convenient and the use is simple and safe!

Specifications:

Table for main technical performance parameters for TC6512A-10 tower crane:
