QTZ80 24KW Self Climbing Tower Crane 140m For Civil Buildings
1. Specification: TC5610A
2. Dimensions: standard section: 1,600mmX1,600mmX3,000mm
3. Material: All main chord be made of Q345B steel
4. Parameter: Maximum hoisting capacity 6 tons, maximum arm length 56m, maximum independent lifting height 40m, maximum attached height 140m
5. Model: QTZ80
Quick Details
1. The tower crane is an outside climbing and self-elevating type with horizontal jib, trolley-luffing and upper slewing
2. The maximum jib length is 56m, the jib length combination reduces for every 6m and the minimum arm length is 44m.
3. The maximum hoisting capacity is 6 tons.
4. The maximum lifting capacity at a distance of 56m is 1.0 ton.
5. The maximum hoisting moment is 93.36t.m.
6. The maximum independent height is 40m and the maximum attached height is 140m.
7. Hoisting mechanism: Adopting a three-speed motor 24KW.
Slewing mechanism: Adopting a double gyration winding motor 3.7 KWX2.
Luffing mechanism: Adopting a double-speed motor 4.0KW.
8. Mast standard section of 1,600mmX1,600mmX2,800mm
Plate standard section of 1,600mmX1,600mmX3,000mm .
9. Tower crane foundation type: Leg fixing type. Stone bolt fixing type
Our main products are:
Topkit tower crane: QTZ63(TC5013), QTZ80(TC5610, TC5610A,TC6010,TC6010A), QTZ100(TC6013-6, TC6013A-6, TC6013-8, TC6013A-8), QTZ125(TC6015-8, TC6015A-8, TC6512-10, TC6512A-10), QTZ160(TC7013-10, TC7013-12), QTZ250(TC7520-12, TC7520-16)
Topless tower crane: QTZ125(TCP6015-8, TCP6512-10), QTZ160(TCP7013-10, TCP7013-12)
Main technical performance parameters for TC5610A tower crane:
|
Mechanism load rate |
Lifting mechanism |
M5 |
|
|
Slew mechanism |
M4 |
||
|
Pulling mechanism |
M4 |
||
|
Rated hoisting moment |
80t.m |
||
|
Lifting height(M) |
Multiplying factor |
Independent fixed type |
Fixed attached type |
|
α=2 |
40 |
140 |
|
|
α=4 |
40 |
70 |
|
|
Hoisting capacity |
Arm length 56m |
Arm length 50m |
Arm length 44m |
|
6/1.0 |
6/1.3 |
6/1.8 |
|
|
Amplitude |
Maximum amplitude |
56 |
|
|
Minimum amplitude |
2.5 |
||
|
Lifting mechanism |
Multiplying factor |
α=2 |
α=4 |
|
Hoisting capacity (t/m/min) |
1.25/80 3/40 |
3/40 6/20 |
|
|
Minimum stable descending speed m/min |
≤5 |
||
|
Power |
24/24 |
||
|
Slew mechanism |
Motor model |
YZR132M2-6-HZ |
|
|
Speed (r/min) |
0.6 |
||
|
Pow |
