CE RoHS 1.2A Constant Current LED Lighting Driver AC 220V With High Voltage Start

Delivery Time:5-10 days
Certification:CE,ROHS

CE RoHS 1.2A Constant Current LED Lighting Driver AC 220V With High Voltage Start

20-30W isolation type constant current LED driver

Part Number: SMDA-2030-PF Brand Name:SEAMOUNT Product description:20-30W isolation type constant current LED driver power supply Output power: 20-30W Input voltage: 85 ~ 265V AC Input frequency: 47 Hz ~ 63 Hz Power factor>0.95 Output voltage: 20 ~ 45 VDC Maximum current: 1.2A Maximum output power: 30 w Conversion efficiency> 89% Constant current precision:±3% Ripple and noise (P - P) ≤5% Temperature coefficient: ±0.2%/℃


Product features:

High voltage start, no delay, no flicker Low ripple, start quickly, high PF, high efficiency Over temperature protection, over-voltage protection, overload protection, short circuit protection Isolated power supply, safe and reliable, Two years warranty, CE, RoHS certification


Electrical properties:

Input voltage:	85 ~ 265V AC
Input frequency:	47 Hz ~ 63 Hz
Power factor	>0.95
Output voltage:	20 ~ 45 VDC
Maximum current:	1.2A
Maximum output power:	30 w
Conversion efficiency	> 89%
Constant current precision:	±3%
Ripple and noise (P - P)	≤5%
Temperature coefficient:	±0.2%/℃

Protection features:

Output no-load voltage≤60V Short circuit protection Over temperature protection Over voltage protection Overload protection


Electromagnetic interference:

Conducted interference degree: EN55015, CLASS B Radiated interference degree: EN55015, CLASS B


Environmental conditions:

Working temperature: 10 ℃ ~ + 45 ℃ typical values (25 ℃) Storage temperature: -20℃～+70℃ typical values (25 ℃) Relative humidity: 5~95% Atmospheric pressure: 70-106 KPa


Certification&life:

EMC:BST13110685Y-1EC-1 LVD:BST13110685Y-1SC-2 RoHS:BST13110685Y-1RC-4 Life: 50,000 hours long life design


Product packaging/size /weight/ quantity:

Driver size/weight: 85mm*39mm*23mm External driver size/weight: 115mm*45mm*28mm Driver packing size/weight/quantity: External driver packing size/weight/quantity:

Application:

Widely used in 20-30W LED Lighting.
