1000V DC Fuse Photovoltaic Combiner Box RS485 6mm For Renewable Photovoltaic Energy

1000V DC Fuse Photovoltaic Combiner Box RS485 6mm² For Renewable Photovoltaic Energy

 Anti reverse solar panel combiner boxes 10 strings ,backflow preventing blocking diode SCB with full protection for power plant and residential use

Quick Detail:

for blocking diode used in combiner box, usually for big solar power plant ,as there is no shade nearby so voltage of all strings are almost the same ,the power will not reverse to other strings.

for small solar system ,there may be installed near the tree or the building ,some times if there is shade on some of the panels  ,these shade covered strings panels may not work as  designed ,and the output voltage of different strings may be much different, for the strings no shade ,instead of output to the inverter ,the power may be reverse  back to the shade covered strings, and damage the system  .Also it will cause  waste the power. To prevent the reverse of the power, we suggest using anti reverse diode on those residential systems.

Description:

High quality multi-strings PV combiner box for solar power system

The PV combiner box is used for connecting serial PV arrays into combiner box in parallel , it’s used together with controller, DC power distribution cabinet , solar inverter  and AC power distribution cabinet etc

to consists of a completed solar power generation system . In order to improve the system’s stability and

practical applicability ,we collocate the PV dedicated DC lighting protection module , DC fuses and break etc

inside the PV combiner box , and It can detect the system parameters , also very convenient for customers

get the information on solar cellswork situation,thereby to promise the solar power generation system bring into

the max effect .Performance featuresSwitching on multi-strings PV series at the same time available ,

Outdoor installed usage is available ,Using PV dedicated DC fuse and lighting protection module,

The current of each road can be monitored  with 485 communication moduleincluded ,

finalizing remote monitoring and management

for blocking diode used in combiner box, usually for big solar power plant ,as there is no shade nearby so voltage of all strings are almost the same ,the power will not reverse to other strings.

for small solar system ,there may be installed near the tree or the building ,some times if there is shade on some of the panels  ,these shade covered strings panels may not work as  designed ,and the output voltage of different strings may be much different, for the strings no shade ,instead of output to the inverter ,the power may be reverse  back to the shade covered strings, and damage the system  .Also it will cause  waste the power. To prevent the reverse of the power, we suggest using anti reverse diode on those residential systems.

Specifications

1.PV modules are access high pressure fuse
2.PV array anti-reverse protection
3.PV array is converge-wires

Solar Combiner Box / PV  Combiner Box /  Solar Array Combiner /  Solar photovoltaic system combiner box

Key features:

1. According to the function, it will have a standard combiner box   and an intelligent combiner box

According to different working environment, it will have polycarbonate (PC) and steel made boxes .

2.We choose all materials strictly on quality first principle. All components comply with DIN and VDE standards, and all adhere to the highest quality standards.
3.CE, TUV, CQC certified.

4,Meet outdoor installation requirements, IP66 . With anti-UV, anti-acid, anti-alkali, moisture, mildew, rodents and so on functions.

5,All components meet rated voltage DC1000 V requirements.

6.With fuses on Inputs, switches on outputs, and SPD in both poles.

7,Can monitor the current of each string, system voltage, status of circuit breaker and SPD. Can display and read the data on both local and background part. Can accurately identify the fault and its position

Applications:

Solar can be transformed into electricity that can be used directly or fed into the grid according to national policy. Longmax Technology is focused on developing and offering technology and products for sustainable solar energy development.

In the field of sustainable renewable photovoltaic energy, our core competencies products include:

Solar combiner boxes, AC/DC distribution cabinets/boxes, intelligent monitoring devices, portable AC/DC solar generators, multi-function power systems, environmental monitoring instruments, PV prevent reverse diodes and
