PH8mm, PH9.6mm, PH12mm Large RGB Rental LED Screen for Brightness 2000 Nits

ITEM

P4

P6

P8

P9.6

P12

Pixel Pitch

4 mm

6.0mm

8.0mm

9.6mm

12mm

Pixel Configuration

1R1G1B

1R1G1B

1R1G1B

1R1G1B

1R1G1B

Module Size

576 x 192mm

Cabinet Size

576 x 576 mm

Pixel Density

62500 dot/㎡

27777 dot/㎡

15625 dot/㎡

10850 dot/㎡

6944 dot/㎡

Scan Mode

1/16

1/8

1/8

1/4

1/4

Gray Level

14-bit

14-bit

14-bit

14-bit

14-bit

Brightness

2000 nits

2000 nits

2000 nits

2000 nits

2000 nits

Contrast Ratio

3000:1

3000:1

3000:1

3000:1

3000:1

Refresh Rate

2000 Hz

2000 Hz

2000 Hz

2000 Hz

2000 Hz

Viewing Angle

160°/120°

160°/120°

160°/120°

160°/120°

160°/120°

View Distance

4m-40m

6m-60m

8m-80m

9.6m-96m

12m-120m

Adjust level

256

256

256

256

256

Failure rate of Pixel

<1/10, 000

<1/10, 000

<1/10, 000

<1/10, 000

<1/10, 000

Working Voltage

AC110/220V ±10%, 50~60Hz

Ave.Power cons.

205 W/sqm

185 W/sqm

105 W/sqm

145 W/sqm

95 W/sqm

Working Life

>50, 000 Hours

Working

environment

-30℃~55℃, RH10~90%
